Product Details
| Place of Origin | Guangdong, China | Brand Name | SOMMY | |
| Model Number | RMH | Theory | Solid State Relay | |
| Usage | General Purpose | Size | Miniature | |
| Protect Feature | Epoxy | Contact Load | Low Power |
Product Description
Heat Sinks with SSR
Features:
1.High bright LED for input indication
2.With inrush current absorb circuit inside the SSR
3.Control block applying constant current circuit
And it is not necessary to connect a current-limit resistance in serial within 5-32V
Ordering Code
Model | Rated current | Control voltage | Rated voltage | Activation type | Disconnect critical voltage rising rate |
RMH-15A400 | 15A |
5~300V DC |
400V |
Zero-cross ( or random ) |
500V / μs |
RMH-25A400 | 25A | ||||
RMH-40A400 | 40A | ||||
RMH-60A400 | 60A | ||||
RMH-80A400 | 80A |
Technical Specification
Applicable load type | AC1 |
| Zero-corss area of SSR | ±15V |
Inrush current (1 cycle) | 700% |
|
|
|
DVS/DT | 500V / |
| Insulation voltage | ≥15V |
DVC/DT | 100V / |
|
|
|
Voltage drop when active | <2V |
| Ambient temperature | -30°C to 75°C |
Power net frequency | 50HZ/60HZ |
| Max.active delay for zero-cross type SSR |
10ms |
Max. inactive delay | 100ms |
|
