Specifications
a. Good resistance thermometer clementb. Factory sell directory
c. Normally 0.4mm wire diameter, stainless wire
d. OEM/ODM
Description |
Code |
Type |
Feature |
Pressure thermocouple |
WRNT-01 |
K |
Fixed screw thread: M12×1.5 M10×1.5 M8×1.5 |
WRET-01 |
E |
||
WRJT-01 |
J |
||
Pressurethermal resistance |
WZPT-01 |
PT100 |
|
WZCT-01 |
Cu50 |
Description |
Code |
Type |
Feature |
Screw thermocouple |
WRNT-02 |
K |
Fixed screw thread: M6×1 M8×1 |
WRET-02 |
E |
||
WRJT-02 |
J |
||
Screw thermal resistance |
WZPT-02 |
PT100 |
|
WZCT-02 |
Cu50 |
According to the national standards and verification regulations. When measuring the temperature of large containers, boilers, the flue, furnace, big flow loop body, large diameter pipe, such as prefabricated thermocouple and thermal resistance, should be adopted fabricated thermocouple and thermal resistance; When measuring the temperature of the small system, small equipment should choose simple thermocouple, thermal resistance; When measuring temperature higher than 300 °C, should select the thermocouple as temperature sensor; when measuring temperature below 200 °C, should choose thermal resistance as temperature sensor; When the temperature measurement temperature higher than 800 °C, should be adopted the material of steel tube, ceramic tube as a protection tube, when measuring flow with particles of fluid temperature, should choose wear resistant material for protecting tube
