Product Details
| Place of Origin | Guangdong, China | Brand Name | SOMMY | |
| Model Number | AN708-7-R/Q/C38 | Usage | Industrial | |
| Theory | Temperature Controller | Accuracy | 0.3% | |
| Temperature Range | -199.9-1800C |
Product Description
AN708 series intelligent PID digital temperature controller
Features
1.Universal signal input,suitable for most sensors.
2. With digital LED display,control and multi alarms function
3. Pid control and on-off contorl , auto-pid tuning function
4. RS485 Communication function, Modbus Protocol
5.Modularization output design, easy to change
6. Panel size: 48HX48W mm , 48WX96Hmm, 72HX72Wmm, 48HX96Wmm ,96WX96Hmm 12:120WX120Hmm
Technical Specification
Power Supply | AC/DC 100-240VAC | Power consumption | 5W |
Accuracy | ±0.3%FS3 | Sampling cycle | 250ms |
Work Environment | -20~50°C ≤85%RH | Response time | ≤0.3s |
Insulation Impedance | 100MΩ | Dielectric strength | 1500V AC 1 minute |
Power interference | Anti burst of pulses electromagnetism interference, for power supply input connector,≥2KV | Measured&display resolution | RTD0.1°C TC 1°C |
Output specification | Relay capacity 250V AC/3A 24V DC/5A Voltage output:24VDC/30mA. For driving SSR 420mA current ouptu: drive load≤600Ω | Input signal | TC:K, S, R, J, E, T, B, N,JP100,PT100, CU50, CU100 Linear voltage:0-10V, 0-50mV Linear curret:4-20Ma Linear resistance:0-400Ω |
1. We offer 3 years warrany period for all of our products.
2. We offer free pre-sales and after-sales service , please call to our technical support line :400-8866-986 or 86-760-88722603 if have any quesiton.
3. We offer OEM and ODM service for you , also offer design and reasearch new product for you .
4. We offer price , promotion and technical support , if you want to be our distributor in your country or region
