Help CenterTR9W Intelligent Heating&Cooling Temperature Controller
Related Products
-
TF6 Industrial Digital Temperature ThermometerUS$ 12 - 18MOQ: 2 Pieces -
TF7 Series Panel Intelligent PID Temperature ControllerUS$ 10 - 20MOQ: 6 Pieces
-
Panel Mounting Intelligent Pid Temperature Controller With RS485 ModbusUS$ 12 - 18MOQ: 2 Pieces
-
Low Price Digital Temperature Controller With RS485US$ 10 - 20MOQ: 2 Pieces
-
TF80 Series Panel Intelligent PID Temperature ControllerUS$ 10 - 20MOQ: 6 Pieces
Specifications
1.With 4-20mA analog output2.Universal Input
3.Heating control auto-tuning function
4.Advanced Fuzzy & PID , RS485
Digital Temperature Controller:
Intelligent temperature Controllers, used in wide variety of industries, is the starting and important tools for the controlling of the temperature to get desired results in various industries. Sommy's Digital(PID) temperature controllers, offer quick setup and provide precise temperature management and control for a variety of applications while offering the better price, design and easy operation. They will be the definite choice for your successful control in any temperature applications.
Features:
- Power supply: 100-240V
- Universal Input: K,J,E,T,PT100,Cu50,Cu100
- Accuracy: ±0.5%F.S ±3digits 25 °C
- Advanced Fuzzy & PID arithmetic
- Optional DC 4-20mA analog output
- Communication:Optional RS485, Modbus RTU (to be ordered)
- Digits display, control ,alarm & adjustable function
- Heating control auto-tuning function
- Control Mode: ON/OFF Control, PID heating control, PID colling control
- Temperature drift:≤0.025%FS/°C
- Total current:<30mA (220VAC)
- 2 Relay contact capacity: AC250V/3A or DC30V/5A
- Input impedance:>100kΩ (0.2mA)
- Ambient Temperature:0-50°C
- Ambient Humidity:45-85RH%
- Panel Protection Level: IP65
- Size available: 4:48W*48H,6:48W*96H,7:72W*72H, 8:96W*48H, 9:96W*96H
Ordering Code
| *Model No. | Alarm No. | Control Output | Input | Communication |
| TR♦-Q20W | 2 | SSR | k,E,T,B,J,PT100,Cu100,Cu50 | No |
| TR♦-R20W | 2 | Relay | No | |
| TR♦-C20W | 2 | 4-20mA | No | |
| TR♦-Q28W(to be ordered) | 2 | SSR | RS485(Modbus RTU) | |
| TR♦-R28W(to be ordered) | 2 | Relay | RS485(Modbus RTU) | |
| TR♦-C28W(to be ordered) | 2 | 4-20mA | RS485(Modbus RTU) |
*Model No. example:
TR4-Q20W indicates: Size 4, SSR output, 2 alarms, no communication;
TR6-R28W indicates: Size 6, Relay output, 2 alarms, RS485 (Modbus RTU)
Note: For 48W*48H Panel size, it is just one alarm / two alarms without communiction. Please consult with us ebfore order.
High Quality and Competitive Price, we proudly take you to enquiry, thank you !
