Ramps or Soaking Controller
- zhongshan/Guangzhou/Ningbo/Shanghai/Shenzhen/HK
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | SOMMY | |
| Model Number | AN808 | Usage | Industrial | |
| Theory | Temperature Controller | Accuracy | 0.5 | |
| Temperature Range | -50~1300'C |
Product Description
Ramps or Soaking controller
AN808 Series Advanced Universal PID Programmable Temperature Controller & adjustor Features:
* 240X160 dot matrix display
* Two freedom degree PID arithmetic
* RS485 Communication function, Modbus Protocol
* Modularization output design, easy to change,Multi alarm output
* With program segment control function
* Multiple input
Model | Alarm | Control Output | Communication | Input |
AN808P-♦-Q2 | 2 alarm 1 cooling control | SSR | NO | K, J, E, T, R, S, B, N, CU50, CU100, PT100,0-10V, 4-20mA, 0-50mV, 0-400Ω |
AN808P-♦-R2 | Relay | |||
AN808P-♦-C2 | 4-20mA Current | |||
AN808P-♦-Q28 | 2 alarm 1 cooling control | SSR | Yes | |
AN808P-♦-R28 | Relay | |||
AN808P-♦-C28 | 4-20mA Current |
Technical parameter
Power supply | AC/DC:100~240V 50/60HZ | Power consumption | 5W |
Accuracy | ±0.3%FS | Sampling cycle | 250ms |
Environment | 0~50°C≤85%RH | Response time | ≤0.3s |
Insulation impedance | 100m Ω | Dielectric strength | 1500V AC 1 minute |
Power interference | Anti-bust of pulses electromagnetism interference, for poer supply input connector,≥2KV | Measured & display resolution | RTD 0.1°C, TC 1°C, for other input, it is selectrable |
Output specification | Relay capacity 250V AC /3A, 24VDC/30mA(For driing SSR) 4-20mA current output: drive load≤600Ω | Input signal | TC:K, J, E, T, R, S, B, N RTD: Cu50, Cu100, PT100,JPT100 Linear voltage:0-10V, 0~50mV Linear current: 4-20mA, Linear resistance: 0-400Ω |
