Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our Agitated Thin Film Evaporator constructed from high-grade 316L stainless steel. With a working pressure range of 0.1–0.5 MPa and an evaporation capacity of 150 L/h, this unit is engineered for efficient concentration and separation of heat-sensitive, viscous, or fouling liquids. As a manufacturer with over 8 years of experience (since 2015), a modern factory spanning 10,000–30,000 m², and an annual export value of US$10–50 million, we ensure that every evaporator meets rigorous quality standards. Our product is designed to maximize heat transfer, minimize residence time, and deliver consistent output, making it an ideal choice for chemical, pharmaceutical, food, and environmental industries.
The Agitated Thin Film Evaporator combines advanced mechanical agitation with a thin film technology to achieve high evaporation rates while maintaining product integrity. The 316L stainless steel construction provides excellent corrosion resistance against aggressive media, and the scraper blades continuously wipe the heating surface to prevent fouling and scaling. Below are the key features and technical specifications.
Key Features & Benefits
- 316L Stainless Steel Construction – Excellent resistance to chlorides, acids, and alkalis; suitable for hygienic and corrosive applications.
- Wide Working Pressure Range (0.1–0.5 MPa) – Allows operation under vacuum or low pressure to reduce boiling temperature for heat-sensitive materials.
- High Evaporation Capacity (150 L/h) – Ideal for small to medium-scale production, pilot plants, or continuous processing.
- Mechanical Agitation System – Patented rotor with adjustable blades ensures uniform film thickness and prevents product degradation.
- Low Residence Time – Product passes through the heated zone in seconds, preserving volatile components and avoiding thermal damage.
- Self-Cleaning Scraper Blades – Continuous wiping action eliminates fouling, reducing downtime for cleaning.
- Compact Design – Space-saving vertical layout, easy to integrate into existing production lines.
- Customizable Heating Options – Steam heating, electric heating, or thermal oil circulation available upon request.
- Compliance with International Standards – Our company holds ISO9001, HACCP, SA8000, and other certifications, ensuring consistent quality control.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | 316L Stainless Steel (body, rotor, blades) |
| Working Pressure | 0.1 – 0.5 MPa (absolute) |
| Evaporation Capacity | 150 L/h (water, at 100°C) |
| Design Temperature | Up to 200°C (higher on request) |
| Heating Surface Area | Approx. 1.5 m² (based on design) |
| Motor Power | 2.2 – 5.5 kW (variable speed) |
| Agitation Speed | 50 – 500 rpm (adjustable) |
| Connections | DN25 – DN80 flanges (custom) |
| Options | Vacuum system, CIP nozzles, explosion-proof motor |
The Agitated Thin Film Evaporator is widely used in concentration, distillation, stripping, and recovery of solvents, polymers, food extracts, pharmaceutical intermediates, and wastewater. Its ability to handle high-viscosity materials (up to 100,000 cP) and solids-containing slurries makes it a versatile tool for process engineers. The low pressure drop across the unit ensures minimal energy consumption, while the 316L stainless steel construction guarantees long service life even in harsh environments.
Why Choose Conqinphi?
With a dedicated team of 201–300 employees and a factory area of 10,000–30,000 m², Qingdao Conqinphi has the capability to deliver high-quality evaporators on time. Our main markets span North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East, reflecting the global trust we have earned. Many of our products have been supplied to leading companies in the chemical and pharmaceutical sectors. We offer comprehensive after-sales support, including installation guidance, technical documentation, and spare parts supply.
Ready to optimize your evaporation process? Contact us today to discuss your specific requirements. Our engineers can customize the evaporator to match your fluid properties, space constraints, and production targets. With Conqinphi, you get a reliable partner backed by years of manufacturing expertise and a commitment to excellence.
Frequently Asked Questions (FAQ)
-
What types of materials can be processed with this evaporator?
It is suitable for heat-sensitive liquids, viscous products, suspensions, and solutions containing solids. Common applications include concentration of fruit juices, recovery of solvents, distillation of pharmaceutical intermediates, and treatment of industrial wastewater. -
Can the evaporator operate under vacuum?
Yes, the working pressure range of 0.1–0.5 MPa includes vacuum conditions. Operating under vacuum reduces the boiling point, which is beneficial for thermally unstable compounds. -
How is cleaning performed?
We can integrate Clean-in-Place (CIP) nozzles for automatic cleaning. The scraper blades also help minimize fouling, making manual cleaning less frequent. A detailed cleaning procedure is provided in the user manual. -
What is the typical lead time?
Lead time depends on customization level. For standard configurations, it is usually 30–45 working days. We can expedite for urgent orders upon negotiation. -
Do you offer spare parts or replacement blades?
Yes, we stock spare parts including scraper blades, seals, and bearings. We can also provide a recommended spare parts list with your initial order. -
Is the evaporator explosion-proof?
An explosion-proof motor and electrical components are available as an option. Please specify if your environment requires ATEX or IECEx certification. -
Can I test the evaporation with my product before purchase?
We offer a pilot testing service at our facility. You can send samples, and our engineers will run tests to determine the optimal parameters and confirm the evaporation capacity. -
What certifications does your company hold?
Our company is certified with ISO9001, ISO14000, OHSAS18001, HACCP, SA8000, and other standards. We follow strict quality control procedures from material sourcing to final inspection.
Conclusion: The Agitated Thin Film Evaporator from Conqinphi delivers reliable performance, high efficiency, and long-term durability. With a proven track record in global markets and a strong manufacturing foundation, we are confident in helping you achieve your evaporation goals. Inquire now for a quotation or technical consultation.
