As a leading manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. introduces the Automatic 10 TPH Falling Film Evaporator crafted from premium 316L Stainless Steel and designed to meet ISO compliance standards. This evaporator represents a breakthrough in efficient thermal separation, delivering reliable performance for industries requiring high-capacity liquid concentration or solvent recovery. With over 9 years of expertise and a factory spanning 10,000-30,000 square meters, we ensure every unit is built with precision engineering and robust quality control.
The 10 TPH capacity makes this evaporator ideal for large-scale operations in food processing, chemical manufacturing, pharmaceutical production, and wastewater treatment. Its automatic control system minimizes manual intervention, reducing labor costs and operational errors. The 316L stainless steel construction guarantees exceptional corrosion resistance, longevity, and hygiene, meeting the stringent requirements of HACCP and other food safety standards. Below, we detail the key features and specifications that set this equipment apart.
Key Features & Technical Specifications
- High-Efficiency Heat Transfer: The falling film design ensures a thin, uniform liquid film over the heating tubes, maximizing heat transfer coefficient and reducing energy consumption by up to 30% compared to conventional evaporators.
- 316L Stainless Steel Construction: All wetted parts are made of 316L SS, offering superior resistance to chlorides, acids, and alkalis, ensuring long service life even in harsh environments.
- Fully Automatic PLC Control: Equipped with a Siemens or equivalent PLC system, the evaporator automatically adjusts feed rate, temperature, pressure, and discharge, enabling 24/7 unattended operation.
- ISO Compliant Design: Manufactured under ISO9001, ISO14000, and OHSAS18001 quality management systems, ensuring consistent product quality and safety.
- Compact Footprint: The vertical falling film configuration minimizes floor space requirements, making it suitable for retrofitting into existing production lines.
- Low Maintenance: The self-cleaning action of the falling film reduces scaling and fouling, and the 316L material resists corrosion, lowering maintenance frequency and costs.
- Customizable Options: Additional features such as MVR (Mechanical Vapor Recompression), CIP (Clean-in-Place) systems, and explosion-proof configurations are available upon request.
| Parameter | Value |
|---|---|
| Evaporation Capacity | 10 TPH (tons per hour) |
| Material of Construction | 316L Stainless Steel |
| Operating Temperature | 60°C – 120°C (adjustable) |
| Operating Pressure | Atmospheric to -0.08 MPa (vacuum) |
| Heating Medium | Steam / Thermal Oil / Hot Water |
| Control System | PLC + HMI Touch Screen (Siemens) |
| Power Consumption | ~45 kW (depending on configuration) |
| Dimensions (L×W×H) | Customizable; typical 8m×3m×6m |
Advantages for Your Business
- Energy Savings: The falling film technology combined with optional MVR can reduce energy consumption by 40%–60% compared to traditional evaporators, significantly lowering your operational costs.
- Higher Product Quality: The short residence time and low operating temperature (under vacuum) preserve heat-sensitive ingredients, making it perfect for dairy, juice, and pharmaceutical applications.
- Scalability: The modular design allows easy integration with existing systems and future expansion. We offer units from 1 TPH to 50 TPH.
- Global Compliance: Our evaporators are designed to meet international standards, including CE, ASME, and GMP, ensuring smooth export to North America, Europe, Southeast Asia, and other regions.
- Reliable After-Sales: With a dedicated team of 200+ employees and an annual export value exceeding US$10 million, we provide comprehensive technical support, on-site installation guidance, and spare parts availability.
Trust & Credibility
Since our establishment in 2015, Qingdao Conqinphi Environmental Technology Group has grown into a trusted partner for clients worldwide. Our factory, spanning 10,000–30,000 square meters, houses state-of-the-art fabrication equipment, and our team of 201–300 skilled professionals ensures every product meets the highest quality standards. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and SA8000, reflecting our commitment to quality, environmental responsibility, and social compliance. Our main markets cover North America, South America, Europe, Africa, the Middle East, and Asia, with a strong reputation for delivering reliable, efficient evaporation solutions.
We invite you to experience the difference that precision engineering and customer-centric service can make. Contact us today for a customized quotation or to discuss your specific evaporation requirements. Our team is ready to provide technical drawings, performance data, and references from satisfied clients around the globe.
Frequently Asked Questions (FAQ)
-
What is the minimum order quantity for this evaporator?
We typically accept orders for one unit, but custom configurations may require a minimum quantity depending on complexity. Please consult our sales team for details. -
Can the evaporator handle viscous or fouling liquids?
Yes, the falling film design is effective for moderate viscosity fluids. For highly viscous or heavily fouling liquids, we recommend optional modifications such as forced circulation or scraped surface evaporators available upon request. -
What is the lead time for production?
Standard lead time is 8–12 weeks after order confirmation, depending on configuration and current workload. Expedited delivery may be arranged with prior discussion. -
Do you provide installation and commissioning services?
We offer remote technical guidance and can dispatch engineers for on-site installation and commissioning at an additional cost. Our team also provides training for your operators. -
Is the evaporator compliant with FDA or GMP standards?
Yes, the 316L stainless steel construction and smooth surface finish meet FDA and GMP hygiene requirements. Optional certifications can be provided upon request. -
Can I get a sample or pilot test before purchasing?
We have a pilot-scale falling film evaporator available for testing at our factory. We also welcome customers to send their materials for process evaluation. -
What warranty do you offer?
We provide a standard 12-month warranty from the date of shipment, covering manufacturing defects. Extended warranty options are available. -
How do you support after-sales service for international customers?
We have a dedicated international after-sales team that provides email/phone support, spare parts supply, and remote troubleshooting. We also have partner service centers in select regions.
