Compact Multi-effect Evaporation Concentration Unit With 1.5kW Compressor and 150°C Max Temp
Product Spotlights
Compact multi-effect evaporation unit with 1.5kW compressor achieves high concentration at up to 150°C, reducing energy costs by up to 60%. Customizable capacity, SS304/316L construction, PLC control, and low maintenance. Ideal for wastewater, chemical, and pharmaceutical concentration.
US$ 2790 - 68300
MOQ: 1 Combo
Key Specifications
Get Latest Price
compressor_power:
1.5 kW
max_temperature:
150°C
evaporation_type:
Multi-effect evaporation
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
20 days
Related Products
-
CE Compliant Multi-effect Evaporation System With 0.5-2 T/H Capacity and Touch Screen OperationUS$ 2790 - 68300MOQ: 1 Combo -
Industrial Multi-effect Evaporator With 4-Effect Design and Energy Recovery Rate Up to 95%US$ 2790 - 68300MOQ: 1 Combo
-
Semi-auto Multi-effect Evaporator Concentrator With 304SS Coils and 10kW Power InputUS$ 2790 - 68300MOQ: 1 Combo
-
304 Stainless Steel Multi-effect Evaporation Concentration Crystallization Equipment With PLC Control for 500L/h CapacityUS$ 2790 - 68300MOQ: 1 Combo
-
Pharmaceutical Grade Multi-effect Evaporation Concentration Equipment for API PurificationUS$ 2790 - 68300MOQ: 1 Combo
compressor_power
1.5 kW
max_temperature
150°C
evaporation_type
Multi-effect evaporation
material
Stainless steel (SS304/SS316L)
capacity_range
Customizable (available upon request)
control_system
PLC with touch screen
application
Wastewater treatment, chemical concentration, pharmaceutical processing
port_of_shipment
Qingdao, China
Optimized for high-efficiency concentration, the Compact Multi-effect Evaporation Concentration Unit with 1.5kW Compressor and 150°C Max Temp is designed to meet the rigorous demands of modern industrial processing. As a leading manufacturer from Qingdao Conqinphi Environmental Technology Group Co., Ltd., we integrate advanced thermal engineering with compact footprint to deliver a reliable solution for reducing liquid waste volume and recovering valuable resources. This unit leverages multi-effect evaporation technology combined with a energy-efficient compressor, enabling low-temperature evaporation with minimized energy consumption.
Core features and technical specifications:
- Compressor power: 1.5 kW – ensures stable and efficient vapor compression, reducing overall energy usage.
- Maximum operating temperature: 150°C – suitable for concentrating heat-sensitive materials and various industrial solutions.
- Multi-effect design: Achieves high concentration ratios by reusing latent heat from vapor, significantly lowering steam consumption.
- Compact footprint: Space-saving structure ideal for facilities with limited floor space.
- Material of construction: Standard stainless steel 304 (SS316L optional) for corrosion resistance and durability.
- Control system: PLC with human-machine interface for automated operation and real-time monitoring.
- Capacity: Customizable per client requirements – typical ranges from 100 L/h to 1000 L/h (details available upon request).
- Safety features: Equipped with over-temperature, over-pressure protection and emergency shutdown.
Technical parameters (typical):
| Parameter | Value |
|---|---|
| Compressor Power | 1.5 kW |
| Max Temperature | 150°C |
| Evaporation Capacity | Customizable (e.g., 200 L/h) |
| Energy Consumption | ~0.8 kWh per liter evaporated (typical) |
| Operating Pressure | Negative pressure (vacuum) controlled |
| Material | SS304 / SS316L (optional) |
Benefits for your business:
- Energy savings: Multi-effect design and compressor reuse heat, reducing operational costs by up to 60% compared to traditional single-effect evaporators.
- Low maintenance: Fewer moving parts and robust stainless steel construction ensure long service life with minimal downtime.
- Versatile application: Suitable for concentrating wastewater, brine, chemical solutions, food extracts, and pharmaceutical intermediates.
- Environmentally friendly: Reduces liquid waste volume, lowers disposal costs, and enables water recovery.
- Ease of installation: Compact and skid-mounted design simplifies on-site setup.
Why choose Qingdao Conqinphi Environmental Technology?
Established in 2015, our factory spans 10,000–30,000 square meters with a dedicated team of 201–300 employees. We have an annual export value of US$10–50 million, serving markets across North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. Our quality management systems comply with international standards (including ISO9001, ISO14000, OHSAS18001, and others). With strong R&D capabilities and strict quality control, we deliver reliable evaporation solutions. Shipment from Qingdao port ensures efficient logistics. Contact us today for a customized solution tailored to your specific concentration needs.
Frequently Asked Questions (FAQ)
-
Q: What is the typical evaporation capacity of this unit?
A: The capacity is customizable; common configurations range from 100 L/h to 1000 L/h. Please provide your specific requirements for a tailored solution. -
Q: Can this unit handle corrosive liquids?
A: Yes, we offer SS316L material options for corrosive media. For extremely aggressive chemicals, advanced alloys may be recommended upon request. -
Q: What is the power consumption per liter evaporated?
A: Typically around 0.8 kWh per liter, depending on feed composition and operating conditions. Actual consumption may vary. -
Q: Is the unit easy to operate?
A: Absolutely. The PLC-controlled touch screen interface provides automated sequences and real-time monitoring, requiring minimal operator training. -
Q: What certifications does this product have?
A: Our factory holds multiple international certifications (e.g., ISO9001, ISO14000, OHSAS18001). Specific product certifications can be provided upon request and per customer requirements. -
Q: What is the maximum operating temperature?
A: The unit is designed for a maximum temperature of 150°C. For higher temperature applications, we can discuss alternative designs. -
Q: Can it be integrated into existing production lines?
A: Yes, the compact design and flexible connection ports allow easy integration. Our engineering team can assist with layout and piping. -
Q: What is the warranty period?
A: Standard warranty is 12 months from commissioning. Extended warranty options are available upon negotiation.
