As a professional manufacturer of environmental protection equipment, Qingdao Conqinphi Environmental Technology Group Co., Ltd. offers the Multi-effect Evaporator Concentrator designed specifically for chemical effluent reduction. This system integrates automatic CIP (Clean-in-Place) technology, ensuring high operational efficiency and low maintenance requirements. With over 250 employees and a factory spanning 20,000 square meters, we have the capacity to deliver high-quality industrial evaporators tailored to your needs.
Key Features:
- Multi-effect evaporation design: Reduces energy consumption by utilizing vapor from previous effects.
- Automatic CIP system: Allows cleaning without disassembly, reducing downtime.
- Corrosion-resistant materials: SS316L or higher for harsh chemical environments.
- PLC-based control: Touch screen interface with remote monitoring.
- Modular design: Easy to expand capacity.
- Condensate recovery: Recycles water for reuse.
- Concentrated effluent: Reduces volume by 90-95%, lowering disposal costs.
- Low scaling tendency: Optimized flow patterns.
Technical Specifications:
| Parameter | Specification |
| Evaporation Capacity | 500 kg/h to 5000 kg/h (customizable) |
| Number of Effects | 3, 4, 5, 6, or 7 |
| Operating Temperature | 60°C to 130°C |
| Vacuum Degree | -0.08 to -0.095 MPa |
| Heating Medium | Steam, thermal oil, or electricity |
| Material of Construction | SS304, SS316L, Duplex |
| Control System | PLC + HMI (Siemens, Mitsubishi, or equivalent) |
| CIP System | Automatic, multi-step cleaning cycle |
| Power Supply | 380V/50Hz (3-phase) or customized |
| Dimensions | Depending on capacity |
Advantages for Customers:
- Reduces effluent volume by up to 95%, lowering disposal costs.
- Recycles condensate water for reuse, saving fresh water.
- Recovers valuable chemicals or by-products, creating additional revenue.
- Energy-efficient operation reduces carbon footprint.
- Automatic CIP reduces labor and cleaning time.
- Long service life with minimal maintenance.
Since 2015, Conqinphi has been dedicated to environmental technology. Our main markets include North America, Europe, Asia, Africa, and Oceania. We have exported equipment worth US$10-50 million annually. Our certifications include ISO9001, ISO14000, OHSAS18001, SA8000, and others. We have a strong after-sales team and provide installation, commissioning, and training services. Choose Conqinphi for reliable and efficient effluent reduction solutions.
Frequently Asked Questions
Q: What types of chemical effluent can this evaporator handle?
A: It is suitable for high COD, high salinity, and viscous waste streams, including those containing inorganic salts, organic solvents, and acids.
Q: How does the automatic CIP system work?
A: The CIP system automatically circulates cleaning solution through the evaporator tubes and chambers at programmed intervals, removing scale and fouling without manual disassembly.
Q: What is the energy saving compared to single-effect evaporators?
A: Multi-effect design saves up to 70-90% of energy consumption, as each effect uses the vapor from the previous one.
Q: Can the capacity be customized?
A: Yes, we offer capacities from 500 kg/h to 5000 kg/h and beyond, based on your specific requirements.
Q: What is the typical lifespan of the equipment?
A: With proper maintenance, the evaporator can last over 15-20 years. The use of corrosion-resistant materials extends service life.
Q: Do you provide installation and after-sales support?
A: Yes, our team offers installation guidance, commissioning, and training. We also have a global service network for quick response.
Q: What certifications do your products have?
A: Our company is certified with ISO9001, ISO14000, OHSAS18001, SA8000, etc. Each evaporator is manufactured under strict quality control.
Q: What is the footprint of the evaporator?
A: The footprint varies by capacity; typical units are compact and designed to fit within standard industrial buildings.
