Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a professional manufacturer established in 2015 with a factory spanning 10,000–30,000 square meters and over 200 skilled employees. Our Semi-auto Multi-effect Evaporator Concentrator with 304SS Coils and 10kW Power Input is designed to deliver efficient, energy-saving concentration for liquid products in food, chemical, and pharmaceutical industries. With semi-automatic control and high-quality 304 stainless steel coils, this equipment ensures consistent performance, easy operation, and long service life.
Key Features & Technical Specifications
- Multi-effect Design: Utilizes multiple evaporation stages to maximize heat recovery, reducing energy consumption by up to 50% compared to single-effect units.
- 304SS Coils: All heating coils are made from food-grade 304 stainless steel, providing excellent corrosion resistance and hygiene compliance.
- 10kW Power Input: Reliable electric heating with precise temperature control, suitable for small to medium production batches.
- Semi-automatic Operation: User-friendly PLC touch screen combined with manual overrides for flexible control.
- Compact Footprint: Space-saving design ideal for pilot plants or laboratories.
- Customizable Capacity: Available in various tank sizes (50L, 100L, 200L, etc.) to meet specific production needs.
- Easy Cleaning: CIP (Clean-in-Place) compatible design minimizes downtime.
Technical Parameters (Sample)
| Parameter | Value |
| Power Input | 10 kW (adjustable) |
| Coil Material | SS304 |
| Evaporation Capacity | 50 – 200 L/h (depending on product) |
| Number of Effects | 2–3 (standard), optional up to 5 |
| Operating Temperature | 60–100°C |
| Voltage | 380V 50Hz (3-phase) or customizable |
| Control System | PLC + Touch Screen |
Advantages for Your Business
- Energy Savings: Multi-effect technology reduces steam/electricity usage, lowering operational costs.
- High Product Quality: Gentle evaporation at lower temperatures preserves heat-sensitive ingredients and flavors.
- Robust Construction: 304SS coils resist scaling and corrosion, ensuring longer equipment life.
- Ease of Operation: Semi-automatic mode reduces labor intensity while maintaining flexibility for experienced operators.
- Versatile Applications: Suitable for fruit juice, milk, herbal extracts, chemical solutions, and waste water concentration.
- Compliance Ready: Designed to meet international hygiene and safety standards (e.g., HACCP principles).
Trusted Partner for Global Clients
As a leading manufacturer with annual export value exceeding US$10 Million – US$50 Million, Qingdao Conqinphi has supplied reliable environmental and food processing equipment to markets across North America, South America, Eastern Europe, Southeast Asia, Africa, Oceania, and the Middle East. We have a dedicated R&D team and strict quality control systems that have earned us multiple certifications including ISO9001, ISO14000, OHSAS18001, and HACCP. Every Semi-auto Multi-effect Evaporator Concentrator undergoes rigorous testing before shipment from our Shandong factory. With over 200 employees and a 10,000+ sqm facility, we are fully capable of delivering customized solutions and prompt after-sales service. Choose Conqinphi for reliable performance and professional support.
Frequently Asked Questions
Q1: What is the difference between single-effect and multi-effect evaporators?
A: Multi-effect evaporators reuse vapor from one stage to heat the next, significantly reducing energy consumption. Our model with 304SS coils offers 2–3 standard effects, saving up to 50% energy compared to single-effect units.
Q2: Can this concentrator handle viscous liquids?
A: Yes, it can process moderate viscosity liquids. For high-viscosity products, we recommend optional forced circulation or a scraper system (available upon request).
Q3: What materials of construction are available besides 304SS?
A: 304SS is standard for coils. Tanks can be made of 316L stainless steel for highly corrosive applications (customizable).
Q4: Is the operation fully automatic?
A: No, it is semi-automatic – you can set parameters via the touch screen, but some manual actions (e.g., valve adjustments) are required. Full automatic control can be customized for an additional cost.
Q5: What voltage and frequency do you support?
A: Standard is 380V 50Hz 3-phase. We can customize for 220V 60Hz or other specifications as needed.
Q6: How long is the delivery time?
A: Typically 30–45 days after order confirmation, depending on configuration and quantity.
Q7: What after-sales support do you offer?
A: We provide installation guidance, commissioning support, spare parts supply, and online technical assistance. Our service team is available in multiple time zones.
Q8: Can I get a small lab-scale unit for trial before purchasing a production model?
A: Yes, we offer pilot-scale evaporators with similar design. Please contact us for details.
