As a leading manufacturer based in Qingdao, China, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been dedicated to providing advanced environmental treatment solutions since 2015. Our Multi-effect Evaporation Concentration Equipment is designed with robust engineering and a 1-year warranty, ensuring reliable performance for your industrial processes. Each unit comes with a Mill Test Report to guarantee material quality and compliance. With a factory spanning over 10,000 square meters and annual exports exceeding US$10 million, we deliver equipment trusted across global markets.
Our multi-effect evaporator utilizes a series of heat transfer stages to efficiently concentrate liquid solutions, significantly reducing energy consumption compared to single-effect systems. The equipment is widely applied in wastewater treatment, chemical processing, pharmaceutical industries, and food production, where concentrated by-products or purified water are required. By leveraging multiple effects, the system reuses vapor from each stage, achieving outstanding thermal efficiency and lowering operating costs.
Key Features & Technical Specifications
- High Energy Efficiency: Multi-effect design reduces steam consumption by up to 60% compared to single-effect evaporators.
- Durable Construction: Made from high-grade stainless steel (SS304/SS316) to resist corrosion and extend service life.
- Flexible Capacity: Customizable to handle capacities from 1 m³/day to over 100 m³/day, meeting diverse production demands.
- Advanced Control System: Equipped with PLC and HMI for fully automatic operation, minimizing manual intervention.
- Integrated Cleaning: CIP (Clean-in-Place) system available for easy maintenance and reduced downtime.
- Comprehensive Documentation: Every unit includes a Mill Test Report detailing material composition and mechanical properties.
- Wide Compatibility: Suitable for concentrating a variety of solutions including brines, caustic solutions, and organic solvents.
| Parameter | Specification |
| Number of Effects | 3, 4, 5 (optional) |
| Evaporation Temperature | 50–90°C adjustable |
| Operating Pressure | Atmospheric or negative pressure |
| Heating Media | Steam or thermal oil |
| Material | SS304 / SS316 / Duplex |
| Warranty | 1 Year |
| Included Report | Mill Test Report |
The multi-effect evaporation concentration equipment offers distinct advantages for clients seeking to minimize waste volume, recover valuable resources, and reduce energy costs. Its modular design allows for easy scale-up and integration with existing production lines. Additionally, the equipment complies with international quality standards, including ISO9001, ISO14000, HACCP, and others, reflecting our commitment to reliable manufacturing.
Why Choose Qingdao Conqinphi?
As an established manufacturer with over 200 employees and a factory size of 10,000–30,000 square meters, we have the expertise and resources to deliver high-quality equipment. Our annual export value of US$10–50 million demonstrates our capability to serve global markets, including North America, Europe, and Asia. We provide comprehensive after-sales support and the included Mill Test Report ensures full transparency in material quality. Backed by certifications such as ISO9001, ISO14000, SA8000, and OHSAS18001, you can trust our products for long-term, safe operation. Contact us today to discuss your specific evaporation needs and receive a customized solution.
Frequently Asked Questions (FAQ)
1. What does the Mill Test Report include?
It provides certified material chemical composition, mechanical properties, and heat treatment details, ensuring the stainless steel meets required standards.
2. Can the equipment handle highly corrosive liquids?
Yes, we offer SS316 or duplex stainless steel options for enhanced corrosion resistance, suitable for acidic or alkaline solutions.
3. How do you control scaling and foaming during evaporation?
Our system includes optional antifoam injection and a CIP cleaning system. The design also incorporates low-fouling tube geometries to reduce scaling.
4. Is the operation fully automatic?
Yes, the PLC-based control system automatically regulates temperature, pressure, and feed rate. Manual override is also available for maintenance.
5. What is the typical payback period for energy savings?
Due to multi-effect design, energy savings often result in a payback period of 1–2 years, depending on local energy costs and capacity utilization.
6. Can you customize the number of effects?
Absolutely. We can design systems with 3, 4, or 5 effects (or more) based on your required concentration and steam availability.
7. How long does delivery usually take?
Standard models ship within 30–45 days after order confirmation. Customized units may require 60–90 days.
8. Do you provide installation and training?
Yes, we offer on-site installation supervision and operator training, or remote guidance if preferred.
