Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. We are a professional manufacturer specializing in industrial wastewater treatment solutions since 2015. Our 220V Automatic Multi-effect Evaporation Concentrator with 3-Stage Design is engineered to efficiently reduce liquid waste volumes, recover valuable resources, and meet stringent environmental standards. This concentrator combines advanced multi-effect evaporation technology with intelligent automation, offering reliable performance for various industrial effluents.
With a factory area of 10,000–30,000 square meters and an annual export value of US$10–50 million, we have supplied our equipment to North America, Europe, Southeast Asia, and many other regions. Our products are backed by certifications including ISO9001, ISO14000, and OHSAS18001, ensuring consistent quality and safety.
Key Features & Technical Specifications
- 3-Stage Multi-Effect Design – Maximizes thermal efficiency by reusing vapor from each effect, reducing energy consumption by up to 60% compared to single-effect evaporators.
- 220V Power Supply – Suitable for standard industrial electrical grids, simplifying installation and operation.
- Fully Automatic Control – PLC-based system with touchscreen interface for monitoring parameters such as temperature, pressure, and flow rate. Auto-start, auto-stop, and alarm functions minimize manual intervention.
- Corrosion-Resistant Construction – Main body made of high-grade stainless steel (304/316L optional), suitable for acidic, alkaline, and saline wastewater.
- Compact Footprint – Space-saving vertical or horizontal design, ideal for limited floor space in factories.
- Low Maintenance – CIP (Clean-in-Place) system available for easy cleaning, and anti-scaling coatings reduce fouling.
- Customizable Capacity – From 100 L/h to 10,000 L/h (other capacities available upon request).
- Environmentally Friendly – Reduces liquid discharge volume by over 90%, producing concentrated waste that is easier to handle or dispose.
Technical Parameters (Typical Model)
| Parameter | Value |
|---|---|
| Power Supply | 220V / 50Hz (3-phase, other voltages optional) |
| Number of Effects | 3 |
| Evaporation Capacity | 500 L/h (example, customizable) |
| Operating Temperature | 60–120°C (adjustable) |
| Material | SS304 / SS316L |
| Control System | PLC + HMI touchscreen |
| Dimensions (L×W×H) | 3.0m × 1.5m × 2.5m (configurable) |
| Weight | Approx. 2,500 kg |
Benefits for Your Business
By integrating this concentrator into your wastewater treatment line, you can:
- Reduce operating costs – Energy savings from multi-effect design and automatic load adjustment.
- Improve regulatory compliance – Achieve higher concentration factors, minimizing disposal volumes and meeting discharge limits.
- Enhance resource recovery – Recover water for reuse, and in some cases, recover valuable by-products from the concentrate.
- Increase uptime – Robust construction and auto-diagnostic features reduce breakdowns.
- Simplify operation – User-friendly interface and remote monitoring capability (optional).
Trust Qingdao Conqinphi
We have 201–300 experienced employees and export to over 20 countries, serving industries such as chemical, pharmaceutical, food processing, and textile. Our factory is located in Qingdao, Shandong, with convenient port access. Our quality management system is certified to ISO9001, ISO14000, and OHSAS18001, and we continuously invest in R&D to improve evaporation efficiency. Contact us today for a customized solution or a free technical consultation.
Frequently Asked Questions
Q1: What types of wastewater can this concentrator handle?
A: It is suitable for saline, acidic, alkaline, and organic wastewater streams. Please provide a sample analysis for the best configuration.
Q2: How much energy does the 3-stage design save?
A: Compared to a single-effect evaporator, energy consumption can be reduced by approximately 50–60% depending on operating conditions.
Q3: Does it require special installation?
A: It requires a standard 220V 3-phase power supply and a level foundation. Our team provides installation guidance and on-site commissioning support.
Q4: Is the system fully automatic?
A: Yes, the PLC controls all key processes, including start-up, shutdown, temperature regulation, and alarm notifications.
Q5: What material is the evaporator made of?
A: Standard material is SS304; SS316L is available for highly corrosive wastewater. Please advise your waste composition.
Q6: How do I clean the system?
A: We recommend a CIP (Clean-in-Place) system which can be added as an option. Manual cleaning intervals depend on the feedstock.
Q7: What certifications does your company hold?
A: We are certified to ISO9001, ISO14000, OHSAS18001, and other standards as listed on our company profile.
Q8: What is your typical lead time?
A: For standard models, delivery is 30–45 days. Custom orders may take 50–60 days depending on specifications.
