Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents the Automatic PLC Controlled 304 Stainless Steel Wastewater Treatment Plant, specifically engineered to handle ultra-high-strength effluent with COD levels up to 40,000 mg/L at a daily capacity of 10 cubic meters. As a direct manufacturer with over a decade of experience (established in 2015) and a factory spanning 10,000–30,000 square meters, we deliver robust, reliable, and fully automated solutions for industries facing extreme organic loads. This system combines durable 304 stainless steel construction with advanced PLC automation, ensuring consistent treatment performance and minimal manual intervention.
Our treatment plant is designed to tackle challenging effluents from food processing, chemical manufacturing, pharmaceutical, and textile industries. With a treatment process that integrates primary sedimentation, biological treatment, and advanced oxidation, it achieves effective pollutant reduction even under variable inflow conditions. The PLC (Programmable Logic Controller) enables real-time monitoring of key parameters like pH, dissolved oxygen, and flow rate, automatically adjusting aeration and chemical dosing for optimal efficiency.
Below we detail the technical specifications, key features, and measurable benefits that make this system a smart investment for high-strength wastewater management.
Key Features & Technical Specifications
- Material: 304 stainless steel for corrosion resistance longevity in harsh chemical environments.
- Automation: Fully automatic PLC control with touch screen HMI – supports remote monitoring via optional SCADA integration.
- Treatment Capacity: 10 m³ per day (24-hour continuous operation).
- Influent COD Limit: Up to 40,000 mg/L – ideal for high-strength industrial effluent.
- Treatment Process: Integrated grit removal, equalization, anaerobic/anoxic/aerobic (A²O), membrane bioreactor (MBR) or tertiary filtration (optional), and disinfection.
- Power Supply: 380V/50Hz, three-phase (other voltages available upon request).
- Installation: Skid-mounted or modular design for quick on-site assembly and minimal footprint.
- Compliance: Designed to meet discharge standards for BOD, COD, TSS, and pH – adaptable to local regulations.
| Parameter | Specification |
|---|---|
| Model | CQ-WWTP-10 (PLC) |
| Material Grade | 304 Stainless Steel (316L optional) |
| Control System | Siemens or equivalent PLC with HMI |
| Max Inlet COD | 40,000 mg/L |
| Daily Flow | 10 m³/day |
| Treated Effluent COD | ≤ 500 mg/L (customizable target) |
| Operating Temperature | 5°C – 45°C |
| Weight (approx.) | 3,500 kg (skid mounted) |
Advantages for Your Business
- Reliable High-Strength Treatment: The system’s robust design handles COD spikes up to 40,000 mg/L without compromising effluent quality, protecting downstream processes and environment.
- Low Operating Costs: PLC automation optimizes aeration and chemical dosing, reducing energy consumption by up to 20% compared to manual systems. Self-cleaning features minimize maintenance downtime.
- Space-Saving Modular Design: Skid-mounted units require only a small footprint (approx. 20 m²) and can be easily installed on existing concrete pads. Expansion modules available for higher capacity.
- Compliance & Certifications: Our manufacturing facility holds certifications including ISO9001, ISO14000, OHSAS18001, and various other international standards. The product can be adapted to meet local discharge limits (e.g., EPA, EU directives).
- Global Shipping & Support: Shipped from Qingdao Port with complete documentation. We offer on-site commissioning, spare parts, and remote technical support. Over 200 employees and annual export value of $10-50 million prove our reliability.
With a dedicated team of 201–300 employees and an established export network covering North America, South America, Europe, Asia, Africa, and Oceania, Qingdao Conqinphi has delivered hundreds of wastewater solutions worldwide. Our clients benefit from our extensive experience, competitive pricing, and after-sales service. This Automatic PLC Controlled 304 Stainless Steel Wastewater Treatment Plant represents the ideal balance of durability, automation, and high-strength performance.
Contact us today to request a customized design, obtain a quote, or arrange a factory visit. Our engineers are ready to tailor this plant to your specific effluent characteristics and discharge requirements. Invest in a solution that guarantees consistent compliance and operational peace of mind.
Frequently Asked Questions (FAQ)
-
What is the typical footprint of the 10 m³/day plant?
The modular skid occupies approximately 20 m² (5m × 4m). Additional space for chemical storage and sludge handling is recommended. -
Can the PLC system be integrated with existing SCADA?
Yes, our PLC supports Modbus RTU/TCP protocols. Remote monitoring via Ethernet or 4G is available as an option. -
What is the expected lifespan of the 304 stainless steel tanks?
With proper maintenance and neutral pH operation, the lifespan exceeds 15 years. For highly corrosive effluents, we offer 316L stainless steel upgrade. -
Do you provide installation supervision?
Yes, our engineer can travel to your site for commissioning (travel expenses apply). We also offer online video guidance for simple installations. -
How long does production take after ordering?
Standard lead time is 30–45 working days, depending on customization and raw material availability. -
What payment terms do you accept?
We accept T/T (30% deposit, 70% before shipment), L/C at sight, or other negotiable terms for long-term partners. -
Can the plant handle intermittent flow (e.g., 8-hour batches)?
Yes, the system includes an equalization tank and PLC logic that adapts to batch discharge schedules. The design can be optimized for your specific flow pattern. -
What certifications does the product itself hold?
Our production line is certified under ISO9001, ISO14000, OHSAS18001, and others. Individual units can be CE marked or certified per requested standards (cost applied).
