Large Triple Effect Falling Film Evaporator for Chemical Industry Processing
Product Spotlights
Triple-effect falling film design cuts steam consumption by up to 60%; corrosion-resistant SS304/316L construction; PLC automation for precise control; customizable capacity from 1,000 to 50,000 L/h; manufactured in ISO9001/HACCP certified facility with global export experience.
US$ 9900 - 95000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Certification:
Other, ISO9001
Warranty:
12–18 months
Type:
Triple Effect Falling Film
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
20 days
Related Products
-
Biogas Slurry Triple-Effect Vacuum Concentration Equipment for Waste TreatmentUS$ 9900 - 95000MOQ: 1 Combo -
Skid-Mounted MVR Triple Effect Evaporator Plate or Tube Type for Industrial UseUS$ 9900 - 95000MOQ: 1 Combo
-
0.5-80t/h Skid-Mounted MVR Triple Effect Evaporator for DesalinationUS$ 9900 - 95000MOQ: 1 Combo
-
Triple Effect Falling Film Evaporator Tubular or Plate Type for ConcentrationUS$ 9900 - 95000MOQ: 1 Combo
-
Titanium Triple Effect Evaporator for Corrosive Liquid ConcentrationUS$ 9900 - 95000MOQ: 1 Combo
Certification
Other, ISO9001
Warranty
12–18 months
Type
Triple Effect Falling Film
Application
Chemical Industry Processing
Capacity
Customizable (1,000–50,000 L/h)
Material
Stainless Steel 304/316L
Heating Method
Steam or Thermal Oil
Control System
PLC with Touch Screen
Port of Shipment
Qingdao, China
Qingdao Conqinphi Environmental Technology Group Co., Ltd. — a specialized manufacturer with over 10 years of experience in evaporation technology — proudly presents the Large Triple Effect Falling Film Evaporator, designed specifically for high-volume chemical industry processing. Our evaporator combines advanced triple-effect heat recovery with falling film technology to deliver superior energy efficiency, reduced operating costs, and consistent product quality. Built in our 10,000–30,000 m² factory with a skilled team of 200+ employees, each unit undergoes rigorous quality control before export to markets worldwide.
Key Features & Technical Specifications
- Triple-Effect Design: Three stages of evaporation maximize heat utilization, reducing steam consumption by up to 60% compared to single-effect systems.
- Falling Film Technology: Uniform liquid distribution over vertical tubes ensures thin film evaporation, preventing scaling and fouling — ideal for heat-sensitive chemicals.
- Large Processing Capacity: Available in capacities from 1,000 L/h to 50,000 L/h, customizable to match your production needs.
- Corrosion-Resistant Materials: Constructed from SS304 or SS316L to withstand aggressive chemical environments.
- PLC Automation: Touch-screen control with real-time monitoring of temperature, pressure, flow rate, and concentration levels.
- Energy Savings: Integrated vapor recompression (optional) further reduces energy cost.
- Easy Maintenance: Modular tube bundles and CIP cleaning ports reduce downtime.
Technical Parameters (Typical Model)
| Parameter | Value |
|---|---|
| Evaporation Capacity | 5,000 – 50,000 L/h (custom) |
| Number of Effects | 3 |
| Operating Temperature | 60°C – 120°C (adjustable) |
| Evaporation Pressure | Atmospheric / Vacuum (optional) |
| Heating Steam Pressure | 0.3 – 1.0 MPa |
| Material of Construction | SS304 / SS316L (food grade available) |
| Control System | PLC + HMI, remote monitoring ready |
Benefits for Your Chemical Processing
- Lower Operational Costs: Triple-effect design cuts steam usage by 50–60%, reducing your energy bill significantly.
- Higher Product Purity: Gentle falling film evaporation minimizes thermal degradation, preserving product quality.
- Scalable Solutions: We offer customized sizing to match your existing plant layout and throughput requirements.
- Compliance with Standards: Manufactured under ISO9001, ISO14000, and HACCP certified environment, meeting international quality norms.
- Global Support: With annual export value of US$10M–$50M, we ship to 15+ markets including Europe, Americas, and Asia.
As a manufacturer with a 10,000–30,000 m² factory and 200+ experienced employees, Qingdao Conqinphi Environmental Technology Group Co., Ltd. has delivered hundreds of evaporation systems for chemical industries worldwide. All equipment is thoroughly tested before leaving our Qingdao port. We provide complete documentation, installation guidance, and after-sales support. Contact us today to discuss your specific concentration or recovery needs — we’ll provide a tailored solution with competitive pricing and fast delivery.
Frequently Asked Questions
-
Q: What chemicals can this evaporator handle?
A: It is suitable for a wide range of solutions including acids, alkalis, salts, and organic solvents. The material (SS304/SS316L) can be selected based on corrosivity. -
Q: What is the typical energy saving compared to a single-effect evaporator?
A: Triple-effect falling film evaporators generally consume 60–70% less steam than single-effect units, depending on operating conditions. -
Q: Do you provide customized capacity?
A: Yes, we can design systems from 1,000 L/h up to 50,000 L/h or larger, according to your mass balance requirements. -
Q: What is the lead time for delivery?
A: Standard models require 45–60 days; customized units may take 70–90 days. We can expedite based on order volume. -
Q: Is automation included?
A: Yes, a PLC + touch screen control is standard. We can also integrate with your existing DCS system upon request. -
Q: What certifications does the equipment meet?
A: Our factory holds ISO9001, ISO14000, HACCP, OHSAS18001 and other certifications. Specific product certificates (e.g., CE, ASME) are available as optional extras. -
Q: Can the evaporator be used for wastewater concentration?
A: Absolutely. It is widely applied in chemical wastewater treatment to reduce volume and recover valuable byproducts. -
Q: What is the warranty period?
A: We offer 12–18 months warranty against manufacturing defects, with optional extended service contracts.
