Qingdao Conqinphi Environmental Technology Group Co., Ltd., a professional manufacturer established in 2015, proudly presents our Skid-Mounted MVR Triple Effect Evaporator – a cutting-edge solution for industrial wastewater concentration and resource recovery. As a company with over 200 employees and a factory spanning 10,000–30,000 square meters, we have delivered high-quality evaporation systems to clients across North America, Europe, Southeast Asia, and beyond. Our MVR evaporator combines mechanical vapor recompression with triple-effect efficiency, available in either plate or tube type construction, to offer you maximum flexibility and energy savings. This skid-mounted design ensures rapid installation, minimal footprint, and easy integration into existing processes, making it an ideal choice for demanding industrial applications.
The triple-effect configuration significantly reduces energy consumption by reusing vapor from one effect as heating medium for the next. The MVR (Mechanical Vapor Recompression) compressor further boosts energy efficiency by compressing the vapor and reintroducing it into the system. This results in up to 70% lower operating costs compared to traditional multi-effect evaporators. Whether you need to treat high-salinity wastewater, concentrate chemical solutions, or recover valuable by-products, our evaporator delivers reliable performance with minimal downtime.
- MVR Technology: Uses a compressor to recycle vapor, drastically reducing steam consumption.
- Triple Effect Design: Three stages of evaporation maximize thermal efficiency and throughput.
- Plate or Tube Type: Choose between plate heat exchangers (for high heat transfer, easy cleaning) or tube type (for high-fouling fluids).
- Skid-Mounted: Pre-assembled on a structural steel base, includes all piping, valves, pumps, and controls – ready to hook up.
- Corrosion-Resistant Materials: Standard wetted parts are 316L stainless steel; options for duplex, titanium, or other alloys available.
- PLC Automation: Touch-screen control with real-time monitoring, alarms, and remote access capability.
- Low Fouling & Scaling: Optimized flow patterns and anti-scaling design reduce cleaning frequency.
- Customizable Capacity: Evaporation rates from 1,000 L/h to 50,000 L/h per unit, with multiple units for larger projects.
| Parameter | Value |
| Evaporation Capacity | 1,000 – 50,000 L/h (custom) |
| Steam Consumption (per ton water) | ≤ 0.1 ton (with MVR) |
| Power Consumption | 30–200 kWh/ton water (depending on conditions) |
| Operating Temperature | 60–100°C (adjustable) |
| Material | 316L stainless steel (standard) |
| Dimensions (L x W x H) | Custom per skid |
| Control | PLC + HMI touch screen |
Customer Benefits: By choosing our skid-mounted MVR triple effect evaporator, you gain a compact, all-in-one system that reduces installation time by up to 50% compared to field-erected units. The energy savings alone can pay back the investment within 1–2 years in many applications. Additionally, the modular design allows for future expansion – simply add another skid to increase capacity. Our plate or tube type options ensure you get the right heat exchanger for your specific fluid properties, whether it is low-viscosity, high-fouling, or corrosive.
Trust & Reliability: Qingdao Conqinphi Environmental Technology Group Co., Ltd. has been a trusted manufacturer since 2015, with a factory size of 10,000–30,000 square meters and an annual export value of US$10–50 million. Our team of 201–300 employees includes experienced engineers and technicians who ensure each evaporator meets rigorous quality standards. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, SA8000, and others, demonstrating our commitment to quality, environment, and safety. Our products are shipped worldwide from Qingdao Port, and we have served customers in North America, South America, Europe, Southeast Asia, Africa, Oceania, and the Middle East. We offer comprehensive after-sales support, including installation guidance, operator training, and spare parts supply. With our proven track record and dedication to innovation, you can rely on Conqinphi for your industrial evaporation needs.
Contact us today to discuss your specific requirements and receive a customized proposal. Our technical team is ready to help you select the optimal configuration – plate or tube type, capacity, materials, and control options – to achieve maximum efficiency and return on investment.
-
What types of wastewater can this evaporator handle?
It is suitable for a wide range of industrial effluents, including high-salinity wastewater, chemical process streams, pharmaceutical mother liquors, landfill leachate, and food industry concentrates. The plate or tube type option allows you to choose the best configuration for your specific fluid properties (e.g., viscosity, fouling tendency). -
How energy-efficient is the MVR triple effect evaporator?
With MVR technology, steam consumption is typically less than 0.1 ton per ton of water evaporated, compared to 0.5–1.0 ton for conventional evaporators. Power consumption is approximately 30–200 kWh per ton of water, depending on the temperature lift and fluid characteristics. Overall, it can reduce operating costs by 50–70%. -
Is the evaporator customizable for different capacities?
Yes, we offer a wide range of evaporation capacities from 1,000 L/h to 50,000 L/h per skid. Multiple skids can be combined for larger projects. All parameters (material, voltage, control system, etc.) are customizable per your requirements. -
How long does it take to install and commission?
Since the system is skid-mounted and pre-assembled, installation typically takes 1–2 weeks on-site, including connection to utilities and commissioning. Our engineers can provide on-site supervision if needed. -
What certifications does the equipment have?
Our company holds certifications including ISO9001, ISO14000, OHSAS18001, SA8000, and others. The evaporator itself can be designed to meet ASME, CE, or other international standards upon request. -
What is the maintenance requirement?
Regular maintenance includes inspection of the MVR compressor, cleaning of heat exchanger surfaces (scheduled based on fouling), and checking seals, valves, and pumps. We provide a detailed maintenance manual and recommend annual preventive maintenance. -
Can I use the evaporator for batch processing?
Yes, the system can be designed for both continuous and batch operation. The PLC control allows flexible setpoints. If you need batch functionality, please specify during the inquiry. -
What is the warranty period?
We offer a standard 12-month warranty from the date of commissioning, covering defects in materials and workmanship. Extended warranty options are available upon request.
