Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. As a professional manufacturer established in 2015 with a factory covering 10,000-30,000 square meters and a dedicated team of 201-300 employees, we are proud to present our Energy Saving Stainless Steel Triple Effect Evaporator with High Efficiency. This advanced equipment is designed to significantly reduce energy consumption while maximizing concentration performance, making it an ideal solution for industries seeking cost-effective and environmentally responsible evaporation processes. Our annual export value of US$10-50 million to markets worldwide, including North America, Europe, and Asia, reflects the trust and satisfaction of global clients.
The triple effect evaporator operates on the principle of multiple-effect evaporation, where vapor from the first effect is used as heating medium for the second effect, and so on, dramatically reducing steam usage compared to single-effect systems. Crafted from high-quality stainless steel (304 or 316L), this evaporator ensures excellent corrosion resistance, hygiene, and longevity, meeting the rigorous standards of food, pharmaceutical, and chemical industries. With PLC automatic control and customizable parameters, it offers precise operation and minimal labor intervention.
Key Features & Benefits:
- Energy Saving: Up to 40-60% reduction in steam consumption compared to single-effect evaporators, lowering operational costs.
- High Efficiency: Triple-effect design maximizes evaporation rate per unit of energy input, suitable for large-scale processing.
- Stainless Steel Construction: Resistant to corrosion and easy to clean, ensuring product purity and equipment durability.
- Environmentally Friendly: Reduced carbon footprint and waste heat recovery contribute to sustainable production.
- Versatile Applications: Handles a wide range of liquids including wastewater, fruit juice, milk, syrup, and chemical solutions.
- Automatic Control: PLC system with touch screen interface provides real-time monitoring and adjustment of temperature, pressure, and flow.
- Compact Design: Space-saving layout and modular structure simplify installation and maintenance.
Technical Specifications (Standard Model):
| Parameter | Value |
| Evaporation Capacity | 1000 - 10000 L/h (customizable) |
| Steam Consumption (per kg water evaporated) | 0.35 - 0.45 kg steam / kg water |
| Evaporation Temperature | First effect: 85-100°C, Second: 70-85°C, Third: 55-70°C |
| Material | Stainless Steel SS304 / SS316L |
| Control System | PLC + HMI touch screen (Siemens or equivalent) |
| Power Supply | 380V / 50Hz (customizable) |
Our triple effect evaporator is built to meet international quality standards. We hold certifications including ISO9001, HACCP, OHSAS18001, and many more (full list available upon request). The robust design and rigorous testing ensure reliable performance even under continuous operation. Whether you need to concentrate liquid products, recover solvents, or treat industrial wastewater, our evaporator delivers consistent results with minimal maintenance.
Frequently Asked Questions (FAQ):
-
Q1: How does a triple effect evaporator save energy?
A: It reuses vapor from the first effect as heating steam for the second effect, and so on, reducing the total steam consumption by 40–60% compared to a single-effect system. -
Q2: What types of liquids can be processed?
A: It is suitable for aqueous solutions, fruit juices, milk, syrups, chemical liquids, and wastewater with low to medium viscosity. For high viscosity or scaling-prone liquids, optional modifications are available. -
Q3: Is the evaporator easy to clean?
A: Yes, the stainless steel interior is smooth and can be cleaned via CIP (Clean-in-Place) system, which is included as an option. -
Q4: What is the typical lifespan of this equipment?
A: With proper maintenance, stainless steel evaporators can last 15-20 years or more. Regular inspection and replacement of seals and gaskets are recommended. -
Q5: Can the capacity be customized?
A: Absolutely. We offer customization of evaporation capacity from 100 L/h to 20,000 L/h, as well as tailored materials and control systems. -
Q6: What after-sales services do you provide?
A: We provide installation guidance, commissioning support, operator training, and spare parts supply. Our technical team is available for online and on-site assistance. -
Q7: Does the system comply with international standards?
A: Yes, our evaporators are designed according to ISO, CE, and ASME standards (certifications available upon request). We can adapt to local regulations for different markets. -
Q8: How does it compare to a falling film or forced circulation evaporator?
A: The triple effect system is more energy-efficient than single effect. For heat-sensitive materials, we can combine it with falling film design; for high viscosity, forced circulation can be integrated.
Why Choose Qingdao Conqinphi?
With over 9 years of manufacturing experience, a factory spanning 10,000-30,000 m², and a skilled workforce of 200+ professionals, we have supplied high-quality evaporators to clients across North America, South America, Europe, Africa, and Asia. Our annual export value of US$10-50 million demonstrates our reliability and global reach. We adhere to strict quality control systems (ISO9001, HACCP, etc.) and offer competitive prices without compromising performance. Contact us today to discuss your specific evaporation needs—we are ready to provide a tailored solution that maximizes efficiency and reduces your operating costs.
