Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a trusted manufacturer with over 8 years of experience in environmental equipment. Our Three-effect Evaporation Crystallization Plant Vacuum System combines advanced three-effect evaporation technology with a robust vacuum system, all constructed from premium 304 Stainless Steel and equipped with an intuitive Touch Screen Control. This system is designed to efficiently concentrate and crystallize liquid solutions, recovering valuable solids while minimizing energy consumption. Ideal for industries such as chemical processing, pharmaceuticals, food & beverage, and wastewater treatment, our plant delivers reliable performance with high automation and low maintenance requirements. With a factory size of 10,000–30,000 square meters and annual export value exceeding US$10 million, we are committed to providing top-quality, customized solutions to global clients.
Key Features & Technical Specifications
- Three-effect evaporation design – Maximizes energy efficiency by recycling vapor from each effect, reducing steam consumption by up to 60% compared to single-effect systems.
- 304 Stainless Steel construction – Offers excellent corrosion resistance and durability, suitable for acidic and alkaline solutions.
- Vacuum system integration – Lowers boiling point, allowing gentle evaporation of heat-sensitive materials and preventing product degradation.
- Touch Screen PLC Control – User-friendly interface for real-time monitoring of temperature, pressure, flow rate, and automatic adjustments; supports data logging and remote access options.
- Compact footprint – Space-saving layout compared to traditional evaporators, with optional skid-mounted design for easy installation.
- Customizable capacity – Available from pilot scale (50 L/h) to industrial scale (up to 20,000 L/h) – contact us for specific requirements.
- Low maintenance – CIP (Clean-in-Place) capability and easy access to heat exchangers and separators.
| Parameter | Value |
| Number of Effects | 3 |
| Evaporation Temperature | 45–80°C (adjustable via vacuum) |
| Vacuum Level | -0.05 ~ -0.09 MPa |
| Material of Construction | 304 Stainless Steel (316L optional) |
| Control Interface | 7-inch or 10-inch Touch Screen |
| Power Consumption | 3–50 kW depending on model |
| Steam Consumption Ratio | Approx. 0.4–0.5 kg steam per kg water evaporated |
Why Choose Our Three-effect Evaporation Crystallization Plant?
- Energy Savings: The three-effect design recovers latent heat, significantly reducing operating costs.
- High Purity Crystals: Vacuum operation prevents thermal degradation, yielding high-quality crystalline products.
- Automation: Touch screen control with programmable logic reduces human error and labor costs.
- Flexibility: Suitable for a wide range of solutions – brines, organic solvents, acids, and alkalis.
- Global Support: Our experienced team provides installation, commissioning, and after-sales service worldwide.
We are Qingdao Conqinphi Environmental Technology Group Co., Ltd., a manufacturer with a factory area of 10,000–30,000 square meters and a dedicated team of 201–300 employees. Our products have been exported to over 20 countries including North America, Europe, Southeast Asia, and Australia, with an annual export value of US$10–50 million. We hold multiple certifications such as ISO9001, ISO14001, and OHSAS18001, ensuring our manufacturing processes meet international quality and safety standards. With our strong R&D capabilities and commitment to customer satisfaction, we have built long-term partnerships with well-known chemical and pharmaceutical companies.
Invest in a reliable, efficient, and automated evaporation crystallization solution. Contact us today for a customized quotation and technical consultation. Our team is ready to help you optimize your process and achieve higher yields with lower operational costs.
Frequently Asked Questions (FAQ)
-
Q: What is the difference between a three-effect and single-effect evaporator?
A: A three-effect system uses vapor from the previous effect to heat the next effect, conserving steam. It is about 3 times more energy-efficient than a single-effect system, making it ideal for large-scale continuous operation. -
Q: Can this system handle highly viscous or scaling liquids?
A: Yes. The design includes forced circulation or falling film options to handle viscous fluids. For scaling-prone solutions, we recommend a special scraper or self-cleaning heat exchanger – optional upgrades available. -
Q: Is the touch screen control compatible with remote monitoring?
A: Yes. The PLC system supports Modbus RTU/TCP protocols, allowing integration with SCADA or remote monitoring systems. We can also provide a web-based dashboard upon request. -
Q: What materials are available besides 304 SS?
A: We offer 316L stainless steel, duplex stainless steel, and titanium for highly corrosive environments. Please specify your solution composition for material recommendation. -
Q: What is the typical delivery time?
A: Standard models are 30–45 days after order confirmation. Customized systems may require 60–90 days, depending on complexity. We prioritize urgent requests from existing clients. -
Q: Do you provide installation and training?
A: Yes. We offer on-site installation supervision and training for your operators. Remote video guidance is also available for minor adjustments. -
Q: What certifications do your products meet?
A: Our manufacturing facility is certified with ISO9001, ISO14001, OHSAS18001, and many other standards. Specific product certifications (e.g., CE, ASME) can be provided as per your requirements at additional cost. -
Q: Can I test the system with my solution before purchase?
A: Absolutely. We have a pilot-scale three-effect evaporation crystallizer in our lab. You can send your sample for a free feasibility test; we will provide a detailed report and recommended design.
