Multi-effect Evaporation Crystallization System With Installation Guidance and After-sales Service
Product Spotlights
Our Multi-effect Evaporation Crystallization System offers high energy efficiency (up to 40% less steam), automatic PLC control, corrosion-resistant materials, and complete installation guidance with after-sales support. Suitable for ZLD applications. Customizable capacity and effects. Backed by a certified manufacturer with global export experience.
US$ 5450 - 538000
MOQ: 2 Combos
Key Specifications
Get Latest Price
Certification:
Other, ISO9001
After-sales Service:
Installation guidance, commissioning, training, 12-month warranty
Material:
Stainless steel 304/316L (customizable)
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
20 days
Related Products
-
Multi-effect Evaporation Crystallization Unit PLC Controlled Feed Pump Included 220VUS$ 5450 - 538000MOQ: 2 Combos -
Automatic Multi-effect Evaporation Crystallization Machine With MVR Compressor 500L/H CapacityUS$ 5450 - 538000MOQ: 2 Combos
-
Multi-effect Evaporation Crystallization Machine for Salt Recovery in Food Processing IndustryUS$ 5450 - 538000MOQ: 2 Combos
-
300t/d Sodium Chloride and Sodium Sulfate Triple-effect Evaporation SystemUS$ 5890 - 536900MOQ: 1 Combo
-
Forced Circulation Three-Effect Evaporator for Enhanced Chemical ProcessingUS$ 790 - 96500MOQ: 1 Combo
Certification
Other, ISO9001
After-sales Service
Installation guidance, commissioning, training, 12-month warranty
Material
Stainless steel 304/316L (customizable)
Capacity
Customizable (e.g., 1-50 tons/day)
Application
Chemical, pharmaceutical, wastewater treatment, food processing
Operation
Automatic / semi-automatic control
Power Source
Electricity / steam (customizable)
Heating Method
Multi-effect thermal vapor compression / mechanical vapor compression
Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. – a trusted manufacturer since 2015 with over 200 employees and a factory spanning 10,000-30,000 square meters. Our Multi-effect Evaporation Crystallization System is designed to efficiently concentrate and crystallize industrial wastewater, reducing waste volume and recovering valuable resources. With complete installation guidance and comprehensive after-sales service, we ensure your system operates at peak performance from day one. This solution is ideal for achieving zero liquid discharge (ZLD) in chemical, pharmaceutical, and food processing industries.
Key Features & Technical Specifications
- Multi-effect design – Utilizes multiple evaporation stages to maximize energy efficiency, reducing steam consumption by up to 40% compared to single-effect systems.
- High crystallization rate – Achieves over 90% salt recovery with controlled crystal growth, minimizing scaling and fouling.
- Low operating temperature – Operates at 50-80°C under vacuum, suitable for heat-sensitive liquids and reducing corrosion.
- Automatic control – PLC-based system with touchscreen interface for real-time monitoring of temperature, pressure, flow, and concentration.
- Modular construction – Skid-mounted design for easy installation, expansion, and relocation.
- Corrosion-resistant materials – Main evaporator and crystallizer are constructed from SS316L or higher-grade alloys, with optional titanium or Hastelloy for aggressive media.
- Complete after-sales package – Includes on-site installation guidance, operator training, remote troubleshooting, and a 12-month warranty (extendable).
| Parameter | Value (Standard) | Remarks |
| Number of Effects | 2 – 6 effects | Customized per client requirement |
| Evaporation Capacity | 1 – 50 tons/hour | Larger capacity available upon request |
| Steam Consumption | 0.3 – 0.5 kg steam/kg water | Depending on number of effects |
| Operating Vacuum | -0.08 to -0.095 MPa | Maintained by vacuum pump |
| Crystallization Temperature | 50 – 80 °C | Adjustable per materials |
| Power Supply | 380V / 50Hz (3-phase) | Other voltage/frequency customizable |
Benefits to Your Business
- Lower operational costs – Energy-efficient multi-effect design reduces your steam and electricity bills significantly.
- Minimal downtime – Anti-scaling technology and automated cleaning cycles ensure continuous operation.
- Regulatory compliance – Meet stringent environmental discharge standards and achieve ZLD objectives.
- Resource recovery – Recover high-purity salts or byproducts that can be reused or sold.
- Hassle-free installation – Our experienced engineers provide on-site guidance to ensure proper setup and integration.
- Reliable support – 24/7 after-sales hotline, spare parts inventory, and annual maintenance contract options.
With annual exports exceeding US$10 million and a team of 201–300 employees, Qingdao Conqinphi has delivered multi-effect evaporation systems to clients across North America, Europe, Southeast Asia, Africa, and the Middle East. Our products are manufactured under strict quality management systems certified by ISO9001, ISO14000, and OHSAS18001. We have a proven track record of successful installations with zero major complaints. Choose our system with confidence – we back every shipment with installation guidance, after-sales service, and a commitment to your success. Contact us for a customized proposal today.
Frequently Asked Questions (FAQ)
-
Q1: What industries is this system suitable for?
A: It is widely used in chemical, pharmaceutical, food processing, textile, and mining industries for treating high-salinity wastewater and recovering valuable products. -
Q2: Can you customize the system for my specific wastewater composition?
A: Yes, we offer customized design based on a free lab analysis of your feed water. We can adjust materials, number of effects, and auxiliary equipment accordingly. -
Q3: What is the typical delivery time?
A: Standard systems take 45–60 days. Custom configurations may require 60–90 days, depending on complexity. We provide a detailed timeline after order confirmation. -
Q4: Do you provide installation guidance? Is it included in the price?
A: Yes, we provide on-site installation guidance by our engineers. Basic guidance is included; full supervision and commissioning can be arranged at an additional cost. -
Q5: What after-sales support do you offer?
A: We offer 12-month warranty, remote troubleshooting, spare parts supply, and optional annual maintenance contracts. Our service team responds within 24 hours. -
Q6: What certifications does your factory hold?
A: Our factory is ISO9001, ISO14000, and OHSAS18001 certified. We also comply with various international standards upon request. -
Q7: Can this system be integrated with existing wastewater treatment lines?
A: Absolutely. Our skid-mounted design allows easy integration. Our engineers can evaluate your layout and provide a seamless retrofit solution. -
Q8: How do you ensure energy efficiency in your design?
A: Multi-effect evaporation inherently reduces steam consumption. We also add vapor compression (MVR) options for even higher efficiency, and our control system optimizes operation in real time.
