100L/H Triple-Effect Vacuum Evaporator 304 Stainless Steel PLC Automatic Industrial Grade
Product Spotlights
Triple-effect energy-saving design (≥60% efficiency), 304 stainless steel for corrosion resistance, PLC automatic control with HMI touchscreen, 100L/H industrial capacity, low maintenance, skid-mounted compact structure, customizable heating options, backed by ISO-certified manufacturer with global export experience.
US$ 9900 - 95000
MOQ: 1 Combo
Key Specifications
Get Latest Price
Type:
Triple-Effect Vacuum Evaporator
Capacity:
100L/H
Material:
304 Stainless Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
20 days
Related Products
-
Large Triple Effect Falling Film Evaporator for Chemical Industry ProcessingUS$ 9900 - 95000MOQ: 1 Combo -
Biogas Slurry Triple-Effect Vacuum Concentration Equipment for Waste TreatmentUS$ 9900 - 95000MOQ: 1 Combo
-
Skid-Mounted MVR Triple Effect Evaporator Plate or Tube Type for Industrial UseUS$ 9900 - 95000MOQ: 1 Combo
-
0.5-80t/h Skid-Mounted MVR Triple Effect Evaporator for DesalinationUS$ 9900 - 95000MOQ: 1 Combo
-
Triple Effect Falling Film Evaporator Tubular or Plate Type for ConcentrationUS$ 9900 - 95000MOQ: 1 Combo
Type
Triple-Effect Vacuum Evaporator
Capacity
100L/H
Material
304 Stainless Steel
Control System
PLC Automatic
Grade
Industrial Grade
Power Supply
380V/50Hz (customizable)
Heating Method
Steam or Electric (optional)
Application
Wastewater treatment, chemical concentration, food processing
Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents the 100L/H Triple-Effect Vacuum Evaporator, crafted from premium 304 stainless steel and equipped with a PLC automatic control system. This industrial-grade evaporator is designed to maximize energy efficiency through triple-effect heat recovery, reducing operating costs while delivering consistent, high-purity distillate. Ideal for wastewater volume reduction, chemical concentration, and solvent recovery, our evaporator combines robust construction with intelligent automation to meet the demands of modern industry.
Key Features & Technical Specifications
- Triple-Effect Design: Utilizes vapor recompression across three stages, achieving up to 60% energy savings compared to single-effect systems.
- 304 Stainless Steel Construction: Corrosion-resistant and easy to clean, suitable for acidic and alkaline solutions.
- PLC Automatic Control: Touch-screen interface with real-time monitoring of temperature, pressure, and flow; automatic start/stop and alarm functions.
- Compact Footprint: Skid-mounted design saves floor space — dimensions approx. 2500×1200×2000 mm.
- Flexible Heating Options: Steam-heated as standard, with electric heating available upon request.
- Low Maintenance: Self-cleaning cycle and anti-scaling coating reduce downtime.
| Parameter | Value |
| Feed Capacity | 100 L/H |
| Evaporation Temperature | 60–90°C (adjustable) |
| Vacuum Degree | -0.08 to -0.095 MPa |
| Power Consumption | ~5 kW (electrical) |
| Material of Construction | 304 Stainless Steel |
| Control System | Siemens PLC + HMI |
| Weight | Approx. 1200 kg |
Customer Benefits
- Reduce Disposal Costs: Concentrate wastewater up to 80% solids, drastically cutting hauling and treatment expenses.
- Improve Environmental Compliance: Meet discharge limits by recovering clean water for reuse or safe release.
- Minimize Operator Intervention: PLC automation manages the entire process, with remote monitoring capability.
- Durable & Reliable: 304 stainless steel resists corrosion, extending service life beyond 10 years with proper maintenance.
- Quick ROI: Energy savings and reduced waste typically pay back the investment within 12–18 months.
Trust the Experts
Since 2015, Qingdao Conqinphi has delivered over 500 industrial evaporation systems worldwide. Our factory spans 10,000–30,000 m², employing 201–300 skilled workers, with an annual export value of US$10–50 million. We hold multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and SA8000 (as per our quality management system). Each unit undergoes rigorous testing before shipment from Qingdao Port. We serve markets across North America, Europe, Southeast Asia, and the Middle East — our team provides installation guidance, commissioning support, and 24/7 after-sales service.
Experience the difference of a 100L/H Triple-Effect Vacuum Evaporator that combines efficiency, durability, and intelligence. Contact us today for a customized proposal or to schedule a factory visit.
Frequently Asked Questions
-
Q: What types of liquids can this evaporator handle?
A: It is suitable for a wide range of aqueous solutions, including industrial wastewater, brine, fruit juices, pharmaceutical extracts, and solvent recovery. Avoid highly viscous or explosive substances unless customized. -
Q: Is the PLC control easy to operate for non-experts?
A: Yes, the touch-screen HMI offers intuitive menus with preset recipes. Operators can start the system with a single touch, and alarms clearly indicate any issues. -
Q: What is the typical energy consumption compared to single-effect evaporators?
A: Triple-effect design reduces steam consumption by approximately 60%. For example, treating 100 L/h of water, the electrical consumption is only about 5 kW plus steam at 0.3–0.5 kg/h per liter of evaporation (depending on conditions). -
Q: Can I use electric heating instead of steam?
A: Yes, electric heating is available as an option. Please specify your utility availability when ordering. -
Q: How long does installation take?
A: The unit arrives skid-mounted and pre-wired. On-site installation typically requires 2–3 days with basic utilities (power, water, drain) prepared. Our team offers remote or on-site supervision. -
Q: What is the warranty period?
A: Standard warranty is 12 months from commissioning or 18 months from shipment, whichever comes first. Extended warranty plans are available. -
Q: Can the evaporator handle fluctuating feed rates?
A: Yes, the PLC automatically adjusts flow and temperature to maintain optimal performance within ±10% of rated capacity. -
Q: Do you provide spare parts and after-sales support?
A: Absolutely. We stock common spare parts and can ship worldwide within 48 hours. Our technical team is available via phone, email, or video call 24/7.
