Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our Automatic Tubular Three-Effect Evaporator crafted from 304 stainless steel, designed to achieve a maximum evaporation capacity of 5000L/H. Since 2015, our factory spanning 10,000–30,000 square meters has been dedicated to manufacturing high-efficiency concentration and wastewater treatment solutions. This evaporator integrates advanced three-effect technology with automatic control, ensuring reliable performance for demanding industrial processes while reducing energy consumption and operational costs.
Our tubular design maximizes heat transfer efficiency and minimizes fouling, making it ideal for treating high-salinity wastewater, pharmaceutical solutions, food processing liquids, and chemical effluents. With a robust 304 stainless steel construction, the unit offers excellent corrosion resistance and long service life. The automatic PLC control system allows precise regulation of temperature, pressure, and flow rates, enabling unattended operation and consistent product quality.
Key Technical Specifications
| Parameter | Value / Details |
|---|---|
| Model | Automatic Tubular Three-Effect |
| Material | 304 Stainless Steel (SS304) |
| Max Evaporation Capacity | 5000 L/H |
| Number of Effects | Three (3) |
| Heat Source | Steam (optional hot water) |
| Control System | PLC with touch screen, automatic operation |
| Operating Pressure | Negative pressure (vacuum) in latter effects |
| Test Standards | Customizable, compliant with ISO9001, HACCP etc. |
Features & Benefits:
- High Efficiency: Three-effect design reduces steam consumption by up to 60% compared to single-effect units, significantly lowering your operational costs.
- Automatic PLC Control: Integrated sensors and touch-screen interface enable real-time monitoring, automatic start/stop, and alarm functions – minimal operator intervention required.
- 304 Stainless Steel Construction: All wetted parts are SS304, offering excellent resistance to corrosion, scaling, and chemical attack, ensuring hygienic processing and long equipment life.
- Tubular Heat Exchanger: Smooth tube surfaces reduce fouling and simplify cleaning (CIP possible). Suitable for liquids with moderate viscosity or suspended solids.
- Compact Footprint: Vertical or horizontal layout options available to fit your facility space. Modular design allows easy expansion or integration with existing lines.
- Versatile Applications: Ideal for concentrating fruit juice, dairy, pharmaceutical extracts, chemicals, and treating industrial wastewater (e.g., RO reject, brine).
- Energy Recovery: The vapor compression effect in later stages reuses latent heat, further improving thermal efficiency.
Detailed Operation Principle: The unit operates under a vacuum in the second and third effects, lowering boiling points and enabling gentle evaporation of heat-sensitive materials. Feed liquid enters the first effect preheated by steam. Concentrated vapor from the first effect serves as heating medium for the second effect, and so on. The final condensate is collected as clean water (or recycled), while the concentrated product is discharged automatically. All parameters are adjustable via the PLC.
Why Choose Our Evaporator?
- Factory-direct pricing with full technical support from Qingdao Conqinphi, a manufacturer with annual export value of US$10–50 million.
- Over 200 employees dedicated to R&D, production, and quality control ensure reliable products.
- Main markets include North America, Europe, Southeast Asia, and more – proven global acceptance.
- Certifications such as ISO9001, HACCP, OHSAS18001 are available upon request, guaranteeing compliance with international standards.
- Flexible customization: we can adapt heating type, capacity, automation level, and material (e.g., 316L upon request).
Trust & Credibility: With a factory size of 10,000–30,000 sqm and a team of experienced engineers, Qingdao Conqinphi has delivered hundreds of evaporation systems to clients worldwide. Since 2015, we have maintained a strong commitment to quality and innovation. Our equipment is shipped from Qingdao Port, conveniently serving international buyers. We provide installation guidance, commissioning support, and after-sales service. Contact us today to discuss your specific requirements and receive a tailored solution.
FAQ
1. What is the minimum order quantity (MOQ) for this evaporator?
The MOQ is 1 set. We can produce custom configurations based on your needs.
2. Can this evaporator handle high-viscosity liquids?
Yes, the tubular design is suitable for moderate viscosity. For very viscous fluids, we recommend a forced circulation or falling film variant, which we can also supply.
3. What is the expected lifespan of the 304 stainless steel equipment?
Properly maintained, the service life can exceed 15 years. Regular cleaning and avoiding chloride stress corrosion are recommended.
4. Is the unit fully automatic? Can it run unattended?
Yes, the PLC can be programmed for fully automatic operation with alarms. However, we recommend periodic inspection. Unattended overnight operation is feasible with proper safety settings.
5. Do you provide installation and training services?
Yes, we offer on-site installation guidance and training for your operators. Remote support is also available.
6. Can the evaporation capacity be adjusted to lower than 5000L/H?
Yes, the system can be throttled via control valves and PLC settings to operate at reduced capacity (e.g., 3000L/H) when needed.
7. What certifications do you have?
We hold ISO9001, HACCP, OHSAS18001, and other certifications. Specific certificates can be provided upon request.
8. How long does delivery take?
Typical lead time is 30–45 days after order confirmation, depending on customization level.
