Welcome to Qingdao Conqinphi Environmental Technology Group Co., Ltd. — a professional manufacturer founded in 2015, with a factory area of 10,000–30,000 square meters and a dedicated team of 201–300 employees. Our annual export value reaches US$10–50 Million, serving markets across North America, South America, Europe, Asia, Africa, and Oceania. We specialize in high-efficiency evaporation systems, and today we present our 304 Stainless Steel Plate-Type Three-Effect Evaporator with PLC Control, designed for a capacity of 2,000 L/H. This advanced evaporator combines superior corrosion resistance, energy-saving three-effect design, and intelligent automation to deliver reliable performance in demanding industrial environments. Whether you are treating wastewater, concentrating chemical solutions, or processing food ingredients, this evaporator provides a cost-effective and sustainable solution.
Our plate-type three-effect evaporator is engineered for maximum thermal efficiency and minimal footprint. The use of 304 stainless steel ensures excellent durability against a wide range of corrosive media, while the PLC control system offers precise monitoring and adjustment of key parameters such as temperature, pressure, and flow rate. Below we detail its core features, technical specifications, and the tangible benefits it brings to your operations.
Key Features & Advantages
- Three-Effect Design: Utilizes vapor from the first effect to heat the second, and so on, reducing steam consumption by up to 50–60% compared to single-effect evaporators. This directly lowers your operational costs.
- Plate-Type Heat Exchanger: High heat transfer coefficient due to turbulent flow between plates; compact structure saves floor space and allows easy capacity expansion by adding plates.
- 304 Stainless Steel Construction: Resists rust and chemical attack, ensuring long service life even when handling acidic or saline solutions. All wetted parts are made of 304 SS.
- PLC Automatic Control: Siemens or equivalent PLC with touch-screen HMI enables real-time data logging, alarm management, and remote operation. Minimum human intervention required.
- Energy Recovery: Integrated condensate recovery system preheats feed liquid, further improving overall energy efficiency.
- Easy Maintenance: Plate packs can be quickly disassembled for cleaning or replacement; no special tools needed.
- Customizable Options: Available with CIP cleaning system, vacuum pump, feed pump, discharge pump, and automatic concentration control.
Technical Specifications
| Parameter | Specification |
| Model | CQE-2000-3P |
| Evaporation Capacity | 2,000 L/H (water basis) |
| Number of Effects | 3 |
| Material | 304 Stainless Steel (SS304) |
| Heat Transfer Type | Plate Heat Exchanger |
| Control System | PLC + Touch Screen (Siemens/Delta optional) |
| Operating Temperature | 60°C – 120°C (adjustable) |
| Steam Consumption | ~0.4 kg steam / kg water evaporated |
| Power Supply | 380V / 50Hz (customizable voltage/frequency) |
| Dimensions (L×W×H) | Approx. 6,000 × 2,500 × 3,200 mm (customizable) |
Beyond the standard specifications, our team can tailor the evaporator to your specific process requirements. For example, we can adjust the number of plates, integrate a forced circulation loop for high-viscosity liquids, or add a scraper mechanism for crystallizing products. The PLC program can also be customized to include your preferred control logic and data recording intervals.
Benefits for Your Business
- Lower Operating Costs: Three-effect design reduces steam consumption, saving up to 60% energy compared to single-effect units. Payback period typically under 18 months.
- Higher Product Quality: Gentle evaporation at lower temperatures preserves heat-sensitive components, ideal for food and pharmaceutical applications.
- Reduced Downtime: Robust 304 SS construction and modular design facilitate quick maintenance. PLC self-diagnostics alert operators before failures occur.
- Scalable Production: Plate-type configuration allows easy capacity upgrades by adding plate packs, matching your growing production needs.
- Environmental Compliance: Efficient energy use and condensate recovery minimize waste and help meet regulatory discharge standards.
Why Choose Qingdao Conqinphi Environmental Technology Group? As a manufacturer with over 8 years of experience and a factory spanning 10,000–30,000 m², we have delivered hundreds of evaporation systems to clients worldwide. Our product portfolio meets rigorous international standards, and we hold multiple certifications including ISO9001, ISO14000, OHSAS18001, HACCP, and SA8000. All equipment is thoroughly tested before shipment, and we provide comprehensive after-sales support including on-site commissioning and training. We ship from Qingdao Port, ensuring fast and reliable logistics to any global destination.
Our team of 201–300 skilled professionals is committed to continuous improvement and customer satisfaction. With an annual export value exceeding US$10–50 Million, we have built a strong reputation in markets across North America, Europe, Southeast Asia, Africa, and Oceania. Whether you need a standard 2,000 L/H unit or a custom-engineered solution, we are ready to assist.
Contact us today for a detailed quotation, process simulation, or technical discussion. Let our 304 Stainless Steel Plate-Type Three-Effect Evaporator with PLC Control become the cornerstone of your production efficiency.
Frequently Asked Questions (FAQ)
-
Q: What types of liquids can this evaporator handle?
A: It is suitable for aqueous solutions with low to medium viscosity, such as wastewater, chemical process streams, fruit juices, dairy products, and pharmaceutical extracts. For highly viscous or fouling liquids, we recommend a forced circulation configuration. -
Q: How does the three-effect design save energy?
A: In a multi-effect evaporator, the vapor generated in the first effect is used to heat the second effect, and so on. This reuse of latent heat reduces the overall steam requirement by approximately 50–60% compared to a single-effect system. -
Q: Is the PLC control system difficult to operate?
A: No, the HMI touch screen provides a user-friendly interface with intuitive menus. Operators can monitor real-time parameters, set alarms, and modify setpoints with minimal training. Remote monitoring via Ethernet is also available. -
Q: What maintenance is required?
A: Regular inspection of gaskets and plate surfaces is recommended. The plate pack can be opened for cleaning, and the control system provides maintenance reminders. We supply a recommended spare parts list with every unit. -
Q: Can the evaporator be customized for different capacities?
A: Yes, we offer capacities from 500 L/H to 10,000 L/H. The plate-type design allows easy scaling by adding or removing plates. Please provide your specific requirements for a custom design. -
Q: What certifications does your company hold?
A: We are certified under ISO9001, ISO14000, OHSAS18001, HACCP, SA8000, and others. These certifications reflect our commitment to quality management, environmental responsibility, and social compliance. -
Q: What is the delivery time for a standard 2000 L/H model?
A: Typical lead time is 30–45 days after order confirmation, depending on the complexity of customization. We work closely with our production team to meet urgent deadlines when possible. -
Q: Do you provide installation and commissioning services?
A: Yes, we offer on-site installation guidance and commissioning support. Our engineers can travel to your site, or we can conduct remote training via video conference. Detailed manuals are provided in multiple languages.
