Qingdao Conqinphi Environmental Technology Group Co., Ltd. proudly presents our Industrial Tubular Three-Effect Evaporator with CIP Cleaning System and Touch Screen PLC. As a manufacturer with over 8 years of experience and a factory size of 10,000–30,000 m², we engineer this evaporator to deliver high-efficiency concentration and recovery for demanding industrial processes. Its three-effect design maximizes energy savings while the integrated CIP cleaning system and intuitive touch screen PLC ensure hassle-free operation and consistent performance. Whether you're treating wastewater, concentrating chemicals, or processing food ingredients, this evaporator provides reliable, automated evaporation with minimal downtime.
The unit features a tubular heat exchanger arrangement that offers excellent heat transfer rates and is easy to maintain. Each effect is engineered to operate under vacuum, lowering the boiling point of the liquid to save energy and protect heat-sensitive products. The CIP system cleans all internal surfaces automatically, reducing manual labor and cross-contamination risks. The PLC touch screen interface allows operators to monitor temperatures, pressures, flow rates, and alarm conditions in real time, with programmable recipes for different products.
Key Specifications
| Parameter | Value |
| Evaporation capacity | 500 – 20,000 L/h (customizable) |
| Number of effects | 3 (triple-effect) |
| Heating source | Steam / Thermal oil / Electric (optional) |
| Operating vacuum | -0.05 to -0.09 MPa per effect |
| Material of construction | SS304 / SS316L (food-grade optional) |
| Control system | Touch screen PLC (Siemens or equivalent) |
| Cleaning method | Automated CIP with programmable cycles |
| Power consumption | 15 – 120 kW (depends on capacity) |
Product Features & Benefits
- Triple-effect energy efficiency – Reduces steam consumption by up to 60% compared to single-effect evaporators, lowering operating costs.
- Tubular heat exchanger design – Provides high heat transfer coefficients and is resistant to fouling, ideal for viscous or scaling liquids.
- Integrated CIP cleaning system – Automatically cleans tubes and vessels without disassembly, extending equipment life and meeting hygiene standards.
- Touch screen PLC automation – Intuitive HMI for easy parameter setting, data logging, remote monitoring, and alarm management. Reduces operator intervention and human error.
- Vacuum operation – Lowers boiling temperature to protect heat-sensitive products and enhance concentration quality.
- Corrosion-resistant materials – Standard SS304 or optional SS316L, suitable for acidic or chloride-containing feed streams.
- Compact footprint – Vertical triple-effect layout minimizes floor space while maximizing evaporation area.
- Flexible customization – Capacity, number of effects, heating method, and control level are adjustable to match your specific process requirements.
- Low maintenance – Tubular bundles are easy to inspect and replace, and the CIP system reduces manual cleaning frequency.
Our evaporator has been exported to over 20 countries including North America, Europe, Southeast Asia, and Africa, serving industries such as landfill leachate treatment, chemical concentration, and food processing. With annual export value between US$10 Million and US$50 Million and a dedicated R&D department, Qingdao Conqinphi ensures every unit meets international quality standards. Our factory is certified with ISO9001, ISO14000, OHSAS18001, and HACCP, guaranteeing reliable performance and safety. Choose our Industrial Tubular Three-Effect Evaporator for a cost-effective, automated, and cleanable evaporation solution. Contact us today for a tailored quotation and technical support.
Frequently Asked Questions
-
What is the typical evaporation capacity range?
We offer capacities from 500 L/h to 20,000 L/h. Custom sizes beyond this range are also available upon request. -
Can this evaporator handle corrosive liquids?
Yes. The standard material is SS304, but we can upgrade to SS316L or other alloys for strong acids or chlorides. Please specify your feed composition. -
Is the CIP cleaning system fully automatic?
Yes. The CIP program is integrated into the PLC. You can set different cleaning cycles (acid wash, rinse, caustic wash) and the system will execute them automatically. -
What utilities are required for operation?
Steam (or other heating medium), cooling water, compressed air (for valves), and electricity (380V/415V/480V, 50/60Hz). Specific requirements can be customized. -
How long does delivery take?
Standard delivery is 30-60 days after order confirmation, depending on the configuration and capacity. We also provide expedited options for urgent projects. -
Do you offer on-site installation and training?
Yes. We can dispatch engineers for commissioning and operator training. Remote support via video call is also available. -
What is the energy saving compared to single-effect evaporators?
A triple-effect evaporator typically consumes about 0.3-0.4 kg steam per kg of water evaporated, which is 60-70% less than a single-effect unit. -
Is the PLC interface available in multiple languages?
Yes. The touch screen supports English, Chinese, and other languages upon request. We can pre-program your preferred language.
