H07V2-R 90℃ 450/750V PVC Single-core Unsheathed Cable (Class 2 Conductor)
· Self-extinguishing and flame-retardant
· Shall not be used for direct laying on platforms, passages (except for equipotential bonding)
· All common standard colors are available
CE certified for internal wiring of control cabinets, medical technology equipment, electronic components and control devices, as well as installation in protective hoses and pipes in mechanical engineering.
And used as connecting wires for transformers and motors
Conductor material: Copper stranded wire
Conductor type: Conforms to IEC 60228 Class 2
Core insulation: PVC
Core identification: Different colors
Rated voltage: H05V2-R: 300/500V; H07V2-R: 450/750V peak operation
Test voltage: H05V2-R: 2kV; H07V2-R: 2.5kV;
Conductor resistance: +20°C conforms to IEC 60228
Minimum bending radius (fixed): 10 x d
Minimum bending radius (mobile): 15 x d
Operating temperature (fixed, minimum/maximum): -15°C/90°C
Flame-retardant grade: Self-extinguishing and flame-retardant conforming to IEC 60332-1-2
Standard: EN50525-2-31 (IEC 60227-3)
Product identification: Aein beke SHANGHAI AEIN WIRE & CABLE CO.,LTD Model Specification Voltage CE
· Conforms to RoHS
· Conforms to 2014/35/EU Directive ("Low Voltage Directive") CE
· Customization is acceptable for products with special structures, other sizes, and core colors.
Our Advantages
Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch owns a modern production base integrating production, quality inspection, and development. The entire process of the company's production and operation is strictly in line with the requirements of the ISO9001:2000 Quality Management System Standard to implement comprehensive quality control, thus ensuring the product quality. All products produced by our company meet international standards and can directly replace foreign products. It enables you to own products of international standards at a reasonable price.
The main products produced by our company include: Drag chain cables, robot cables, servo cables, braider cables, highly flexible control cables, UL-certified cables, EAC customs-certified cables, CE-certified cables, SAA Australian standard-certified cables, TUV German standard-certified cables, Japanese standard cables, crane cables, drum cables, signal cables, hoist cables, oil-resistant cables, cold-resistant cables, bucket wheel machine cables, overhead traveling crane cables, marine cables, zero-buoyancy cables, armored cables, RS-485, corrosion-resistant, acid and alkali-resistant cables, control cables, BUS cables, national standard CCC cables, PUR polyurethane cables, self-supporting steel cable cables, elevator cables, cables for electrical installation, special cables, etc. After years of development, our company has been recognized by a large number of users for its good reputation and high-quality products.
