RZ1MAZ1-K Concentric Halogen-Free Armored Cable
· Low capacitance
· Flammability
· UL/CSA: VW-1, FT1
· IEC/EN: 60332-1-2
Cable for connecting servo controllers and motors
Suitable for static and occasional flexible use
Suitable for indoor and outdoor installation, air supports, conduits, or direct burial
Conductor material: Fine-stranded, bare copper conductors
Conductor class: Complies with EN60228 standard
Core insulation: XLPE
Stranding: Concentric insulated conductors
Shielding: Galvanized steel wire armor
Outer sheath: Halogen-free polyolefin
Outer sheath color: Specifiable color
Rated voltage: 600/1000V
Test voltage: 3500V
Conductor resistance: UL1581 ASTM Class C
Minimum bending radius (fixed): 6 x d
Minimum bending radius (mobile): 15 x d
Operating temperature (fixed, min/max): -40°C/+90°C
Temperature class (mobile, min/max): -5°C/+70°C;
· Complies with RoHS standard
· Customization is acceptable for products with special structures, other sizes, and colors of cores and sheaths.
Our advantages
Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch has a modern production base integrating production, quality inspection, and development. The entire process of the company's production and operation is strictly in line with the requirements of the ISO9001:2000 Quality Management System standard for comprehensive quality control, thus ensuring product quality. The products produced by our company meet international standards and can directly replace foreign products. This allows you to own products of international standards at a reasonable price.
Our company, Shanghai Aiyin Electric Wire & Cable Co., Ltd. Sichuan Branch, mainly produces the following products: Drag chain cables, robot cables, servo cables, braider cables, highly flexible control cables, UL-certified cables, EAC customs-certified cables, CE-certified cables, SAA Australian standard-certified cables, TUV German standard-certified cables, Japanese standard cables, traveling crane cables, reel cables, signal cables, crane cables, oil-resistant cables, cold-resistant cables, bucket wheel excavator cables, overhead crane cables, marine cables, zero-buoyancy cables, Armored cables, RS-485, corrosion-resistant, acid and alkali-resistant cables, control cables, BUS cables, national standard CCC cables, PUR polyurethane cables, Self-supporting steel cable cables, elevator cables, cables for electrical installation, Special cables, etc. After years of development, our company has been recognized by a large number of users for its good reputation and high-quality products.
