Product Introduction
01 Product Application
Used for buildings or industrial buildings with dense personnel or valuable items; for the connection of key equipment such as elevators, fire protection systems, lighting systems, etc.; in public facilities, such as hospitals, schools, shopping malls, etc., all internal wiring.
02 Product Features
The flame retardancy meets the CPR B2ca-s1a, d0, a1 grade.
The non-propagation performance meets IEC 60332-3-24.
The halogen-free requirement meets IEC60754-1 (total amount of halogen acid gas).
The corrosivity of combustion gas meets IEC60754-2 (acidity).
Low smoke density, meeting IEC61034-2.
03 Technical Certification
Complies with the RoHS standard.
Complies with the CPR certification standard.
Complies with the 2014/35/EU - Directive "Low Voltage Directive" CE.
Product Structure
Conductor material: bare copper or tinned copper
Conductor grade: meets the IEC60228 cl.5 standard
Insulation: XLPE
Core wire identification: black core wire with white numbers (customizable colors)
Stranding: layered stranding
Outer sheath: LSZH
Sheath color: black RAL9005 (customizable colors)
Rated voltage: 0.6/1kV
Test voltage: 4kV
Conductor resistance: meets the IEC60228cl.5 standard
Bending radius: 7.5xd for mobile installation and 15xd for fixed installation
Temperature range: -40°C/+90°C
Flame retardant grade: CPR B2ca-s1a, d0, a1 grade
Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage CE Meter mark
