Help CenterN2xh Cpr Cca-s1a, D1, a1 Class Fire-retardant Cables, 0.6/1kv Xlpe Insulation, Lszh Sheath
Related Products
-
Bitcoin Mining Machine Cables With Epr Insulation and Cpe Sheath, 600v/1000v/2000v, Csa-certified CablesUS$ 0.87 - 0.96MOQ: 1000 Meters -
R90 90°c 600v Xlpe Single-core Cold-bending and Impact-resistant Low-smoke Zero-halogen Csa-certified CableUS$ 0.58 - 0.66MOQ: 1000 Meters
-
Rhh 90°c 600v Xlpe Insulated, Low Smoke Zero Halogen, Single Core Cable, Csa Certified CableUS$ 0.47 - 0.61MOQ: 1000 Meters
-
Rwu75/rwu90 1000v Xlpe Insulated Photovoltaic Cables, Csa Canadian Energy Storage CablesUS$ 0.81 - 1.04MOQ: 1000 Meters
-
Sis -40°c/+90°c 600v/1000v Xlpe Insulated Low-smoke Zero-halogen Main Switchboard CableUS$ 0.77 - 0.92MOQ: 1000 Meters
Product Introduction
01 Product Application
Used for buildings or industrial buildings with dense personnel or valuable items; for the connection of key equipment such as elevators, fire protection systems, lighting systems, etc.; in public facilities such as hospitals, schools, shopping malls, etc., all internal wiring.
02 Product Features
The flame retardancy meets the requirements of CPR Cca-s1a, d1, a1 grade.
The non-flammable spreading performance meets the requirements of IEC60332-3-24.
Halogen-free, meeting the requirements of IEC 60754-1 (total amount of halogen acid gas).
The corrosiveness of combustion gas meets the requirements of IEC 60754-2 (acidity).
Low smoke density, meeting the requirements of IEC61034-2.
03 Technical Certification
Complies with RoHS standards.
Complies with CPR certification standards.
Complies with 2014/35/EU - Guidelines CE.
Product Structure
Conductor material: Bare copper or tinned copper.
Conductor grade: Meets the requirements of IEC60228 cl.5 standard.
Insulation: XLPE.
Core wire identification: Black core wire with white numbers (colors can be customized).
Stranding: Layered stranding.
Outer sheath: LSZH.
Sheath color: Black RAL9005 (colors can be customized).
Rated voltage: 0.6/1kV.
Test voltage: 4kV.
Conductor resistance: Meets the requirements of IEC60228 cl.5 standard.
Bending radius: 7.5xd for mobile installation, 15xd for fixed installation.
Temperature range: -40°C/+90°C.
Flame retardant grade: CPR Cca-s1a, d1, a1 grade.
Product identification: Aein bei ke SHANGHAI AEIN WIRE & CABLE CO.LTD Model Specification Voltage CE Meter mark
