Horizontal Fiberglass Reinforced Plastic (FRP) Storage Tank for Large Volume Acid Alkali Chemical Storage – As a leading manufacturer from Hengshui, Hebei, China, Hengshui City Yike Composite Materials Co., Ltd. (established in 2009) specializes in producing high-performance composite storage solutions. Our horizontal FRP tanks are engineered to safely store large volumes of aggressive acids (e.g., sulfuric, hydrochloric) and alkalis (e.g., sodium hydroxide), offering exceptional corrosion resistance, structural integrity, and long service life. With an annual export value of US$1.5–2.5 million and shipments to North America, Europe, Southeast Asia, Africa, and Oceania, our tanks are trusted by chemical processing, water treatment, and industrial manufacturing facilities worldwide.
Designed for demanding environments, these tanks combine advanced filament winding technology with premium vinyl ester or polyester resins. The horizontal configuration optimizes footprint and load distribution, making them ideal for above-ground storage where space is limited. Key benefits include:
- Superior Corrosion Resistance: Withstands a wide pH range (0–14) and elevated temperatures without degradation.
- Lightweight yet Strong: FRP weighs approximately 1/4 of steel, reducing foundation costs while maintaining high tensile strength.
- Customizable Design: Available in diameters from 2 m to 5 m, lengths up to 15 m, and capacities tailored to your needs.
- Low Maintenance: Non-conductive, non-rusting, and resistant to UV degradation with gel coat protection.
- Safe & Reliable: Manufactured with double-layered construction (corrosion barrier + structural layer) and optional leak detection systems.
Below are typical technical specifications for our horizontal FRP chemical storage tanks. All parameters can be adjusted per project requirements:
| Parameter | Standard Range |
| Diameter | 2.0 m – 5.0 m |
| Length | 4.0 m – 15.0 m |
| Design Pressure | Atmospheric – 0.1 MPa (customizable) |
| Design Temperature | -40°C to +120°C |
| Wall Thickness | 6 mm – 25 mm |
| Hoops & Helical Winding | Continuous fiberglass roving |
| Connections | Flanged nozzles, manways, vents (as per specification) |
In addition to standard features, our horizontal FRP tanks can be equipped with internal linings, external UV protection, insulation jackets, and agitation mounting pads. Every tank is hydrostatically tested before shipment to guarantee leak-tight performance. Whether you require a 10,000-gallon sulfuric acid tank or a 30,000-gallon caustic soda tank, our engineering team works closely with you to meet all dimensional, pressure, and chemical compatibility requirements.
Trusted by global clients – Our Commitment to Quality: Since 2009, Hengshui City Yike Composite Materials Co., Ltd. has exported US$1.5–2.5 million worth of composite products annually to over 10 countries and regions, including North America, South America, Europe, Middle East, and Southeast Asia. Our tanks are shipped from Tianjin and Shanghai ports, ensuring efficient logistics. We adhere to strict manufacturing standards (including ASTM D3299 and ASME RTP-1 references where applicable) and offer a 2-year warranty on workmanship. With a dedicated after-sales team, we provide installation guidance, maintenance tips, and spare parts support. Choose Yike for a reliable partner in chemical storage – contact us today for a customized quotation.
Frequently Asked Questions
- Can these tanks store concentrated sulfuric acid (98%)? Yes, with appropriate resin selection (e.g., vinyl ester). Our tanks can handle concentrations up to 98% at ambient temperature. Please confirm your specific chemical and temperature for a precise material recommendation.
- What is the typical delivery time? For standard sizes (e.g., 10,000 gallons), lead time is 4–6 weeks after order confirmation. Larger or custom tanks may require 8–10 weeks. We work to meet your project schedule.
- Are the tanks UV resistant? Yes, the outer surface is coated with a UV-stable gel coat layer to prevent degradation from sunlight exposure. Additional insulation or painting is optional.
- How are these tanks transported? Horizontal tanks are loaded onto flatbed trucks or in containers, depending on size. For very large diameters, we offer sectional fabrication or on-site assembly options.
- Do you provide installation support? Yes, we provide detailed installation drawings and can arrange on-site supervision by our engineers (travel costs apply). We also offer remote guidance via video calls.
- What is the warranty period? We offer a standard 2-year warranty against manufacturing defects under normal operating conditions. Extended warranties are available upon request.
- Can I get a sample or test coupon? Yes, we can send small test coupons of resin and laminate for your chemical immersion testing. Please contact our sales team to arrange.
- Do you offer tanks with secondary containment or double walls? Yes, we can manufacture double-walled, leak-detection-ready tanks. Please inquire for specific designs and pricing.
