Welcome to Hengshui City Yike Composite Materials Co., Ltd. — a trusted manufacturer with over a decade of expertise in FRP composite products. Our FRP Waste Acid Storage Tanks for Chemical Wastewater Treatment Plants with Leak Detection are engineered to provide a safe, durable, and corrosion-resistant solution for storing aggressive acidic waste streams. Unlike traditional steel or plastic tanks, our FRP tanks combine high mechanical strength with exceptional chemical resistance, significantly reducing maintenance costs and operational risks. With built-in leak detection technology, these tanks offer an extra layer of safety, ensuring early warning of any potential leakage and protecting both your facility and the environment.
Designed specifically for chemical wastewater treatment plants, our tanks are manufactured using advanced filament winding or hand lay-up processes, depending on the size and application. The fiberglass reinforcement and specially formulated resin matrix create a seamless, impermeable barrier that withstands constant exposure to sulfuric acid, hydrochloric acid, nitric acid, and other corrosive chemicals. Each tank undergoes rigorous quality control, including hydrostatic testing and leak detection system calibration, to guarantee reliable performance under demanding conditions.
Key Features & Technical Specifications
Superior Corrosion Resistance: The isophthalic or vinyl ester resin liner provides outstanding resistance to a wide range of acids, alkalis, and solvents, extending tank service life beyond 20 years.
Integrated Leak Detection System: A built-in dual-containment design with interstitial monitoring ports allows continuous detection of any fluid between the inner and outer layers, triggering an alarm at the first sign of leakage.
Customizable Capacity & Dimensions: Capacities from 1,000 liters to over 100,000 liters are available, with height, diameter, and nozzle configurations tailored to your plant layout.
Lightweight & Easy Installation: FRP tanks weigh approximately one-fourth of steel tanks, reducing structural loading and simplifying transportation and installation without heavy lifting equipment.
Low Maintenance: Non-conductive and non-corrodible surface eliminates the need for painting, lining, or cathodic protection, resulting in minimal lifecycle costs.
High Strength-to-Weight Ratio: Engineered laminates provide excellent structural integrity, able to withstand seismic loads and external forces in industrial environments.
UV Protection: Outer gel coat with UV stabilizers prevents degradation from sunlight exposure, ideal for outdoor installations.
Compliance with International Standards: Designed per ASME RTP-1 or BS 4994 guidelines (available upon request), ensuring global acceptance.
Technical Parameters (Typical Values – Customizable)
| Parameter | Standard Range | Options / Remarks |
|---|---|---|
| Design Pressure | Atmospheric (±0.5 psi) | Vacuum or low pressure (up to 5 psi) available |
| Design Temperature | -40°C to +80°C | Up to 120°C with high-temperature resin |
| Wall Thickness | 5 mm – 30 mm (design dependent) | Engineered per mechanical load and chemical exposure |
| Leak Detection Sensitivity | Continuous monitoring with optional remote alarm | |
| Connections | Flanged or threaded (standard sizes 2"-12") | Custom nozzle locations per P&ID |
Benefits for Your Wastewater Treatment Plant
Enhanced Safety: The leak detection system provides early warning, preventing hazardous spills that could harm personnel or the surrounding ecosystem.
Regulatory Compliance: Meet stringent environmental regulations for secondary containment and leak monitoring, avoiding costly fines or shutdowns.
Cost Savings: Lower initial purchase cost compared to stainless steel, plus zero corrosion-related repairs or replacements over the tank's lifetime.
Space Efficiency: Vertical or horizontal configurations available to fit tight spaces; multiple tanks can be interconnected for larger storage capacity.
Customization Without Delay: Our in-house engineering team works with your specifications to deliver a tailored solution within standard lead times of 4–8 weeks.
At Hengshui City Yike Composite Materials Co., Ltd., we have been serving global clients since 2009, with annual exports ranging from US$1.5 million to US$2.5 million. Our products are shipped via major ports such as Tianjin, Shanghai, and Tianjin, reaching markets across North America, South America, Europe, Asia, Africa, and Oceania. We understand the critical role that reliable storage tanks play in chemical wastewater treatment, and we back every unit with comprehensive after-sales support, including installation guidance, spare parts, and technical consultation. Choose Yike for a partnership that prioritizes safety, durability, and environmental stewardship. Contact us today to discuss your waste acid storage requirements and receive a customized quotation with engineered drawings.
Frequently Asked Questions (FAQ)
Q1: What types of waste acids can be stored in these FRP tanks?
A: Our tanks are compatible with a wide range of acids including sulfuric acid (up to 70%), hydrochloric acid (up to 37%), nitric acid (up to 25%), phosphoric acid, and mixed acid waste streams. The resin selection can be tailored for specific chemical compositions.
Q2: How does the leak detection system work?
A: The tank features a double-walled construction with an interstitial space between the inner and outer layers. A sensor or visual indicator is installed at the lowest point of the interstitial space. If the inner wall develops a leak, the liquid will accumulate in the interstitial space, triggering an alarm (visual/audible) or a remote notification, allowing timely intervention.
Q3: Can the tanks be installed outdoors in extreme weather?
A: Yes, the outer gel coat contains UV stabilizers that protect against sunlight degradation. The tank can withstand temperatures from -40°C to +80°C without significant performance loss. For extreme cold, additional insulation options are available.
Q4: What is the typical lifespan of an FRP waste acid storage tank?
A: With proper installation and regular inspection, our FRP tanks can last 20 to 30 years, depending on the chemical concentration, temperature, and operating conditions. The corrosion-resistant liner significantly reduces degradation compared to carbon steel or concrete tanks.
Q5: Do you provide installation and commissioning support?
A: Yes, we offer detailed installation manuals and can provide on-site technical supervision upon request. Our team is also available for remote guidance via video calls. Custom lifting lugs and foundation anchors can be added to facilitate installation.
Q6: What certifications do your tanks have?
A: Our tanks are designed in accordance with international standards such as ASME RTP-1 and BS 4994. Specific certifications (e.g., UL, CE) can be arranged upon customer request and at an additional cost. Please contact us with your requirements.
Q7: Can I get a custom tank with non-standard dimensions or multiple compartments?
A: Absolutely. Our engineering team will design a tank to your exact specifications, including multiple compartments, special nozzle orientations, manways, and integrally molded baffles for mixing applications.
Q8: What is the minimum order quantity (MOQ)?
A: There is no fixed MOQ. We accept orders for single tanks as well as bulk orders. For small custom tanks, lead times may be slightly longer due to mold preparation.
