Help CenterFiberglass FRP Neutralization Reaction Tank Anti-Corrosion Vessel for Acid Alkali Neutralization Process
Product Spotlights
Related Products
-
FRP NaOH Storage Tank 12ft Diameter 20ft Height 150°F Max Working Temperature Chemical StorageNegotiableMOQ: 1 Piece -
Vertical Type Fiberglass FRP Storage Tank Filament Wound Structure for Chemical Waste Liquid StorageNegotiableMOQ: 1 Piece
-
Chemical Fertilizer Plant Special Fiberglass FRP Storage Tank for Fertilizer Raw Acid Liquid StorageNegotiableMOQ: 1 Piece
-
Industrial Fiberglass Reinforced Plastic FRP Concentrated Hydrochloric Acid Storage Tank for Chemical PlantNegotiableMOQ: 1 Piece
-
FRP Waste Acid Storage Tanks for Chemical Wastewater Treatment Plants With Leak DetectionNegotiableMOQ: 1 Piece
Hengshui City Yike Composite Materials Co., Ltd., established in 2009, specializes in advanced FRP solutions for industrial chemical processes. Our Fiberglass FRP Neutralization Reaction Tank Anti-Corrosion Vessel is engineered specifically for the demanding acid-alkali neutralization process, offering exceptional durability and long-term reliability. With annual export values exceeding US$1.5 million, our tanks are trusted by clients across North America, South America, Europe, and Asia for critical chemical handling applications.
This vessel combines superior corrosion resistance with robust mechanical strength, ensuring safe and efficient neutralization reactions in industries such as wastewater treatment, chemical manufacturing, and metal finishing. Each tank is custom-designed to meet specific process requirements, from small-scale batch operations to large continuous flow systems.
The following sections detail the key features, technical specifications, and benefits that make our FRP neutralization tank a smart investment for your facility.
Key Features and Advantages
- Superior Anti-Corrosion Performance: Built with a high-grade vinylester or epoxy resin inner layer that withstands continuous exposure to strong acids (e.g., H₂SO₄, HCl) and alkalis (e.g., NaOH) up to 120°C, preventing premature failure and reducing maintenance costs.
- Customizable Capacity and Dimensions: Available in capacities from 500 liters to 50,000 liters with tailored diameter and height to fit your existing plant layout, whether vertical or horizontal configuration is required.
- Lightweight Yet Strong: FRP material offers a high strength-to-weight ratio, allowing easier transportation and installation compared to steel or concrete tanks, while still handling operating pressures up to 0.6 MPa.
- Integrated Design for Process Efficiency: Options include built-in baffles, agitator mounting flanges, nozzles, manholes, and sight glasses to optimize mixing and neutralization kinetics.
- UV and Weather Resistant Outer Layer: An outer gel coat with UV inhibitors prevents degradation from sunlight, making the tank suitable for both indoor and outdoor installations.
- Low Lifecycle Cost: No need for expensive coatings or linings; the monolithic FRP structure eliminates seams and joints that are common failure points in metal tanks.
Technical Specifications (Typical Parameters)
| Parameter | Value / Range | Remarks |
|---|---|---|
| Working Pressure | Atmospheric to 0.6 MPa (6 bar) | Higher pressure available on request |
| Working Temperature | -20°C to +120°C | Peak temperature tolerance up to 150°C for short durations |
| Nominal Capacity | 500 L – 50,000 L | Customizable per process requirement |
| Wall Thickness | 5 mm – 30 mm | Designed based on load and chemical resistance factors |
| Resin Type | Vinylester / Epoxy / Isophthalic Polyester | Selected per chemical environment |
| Fiber Reinforcement | E-glass / C-glass / Carbon (optional) | Chopped strand mat, woven roving, or combination |
| Connections | Flanged / threaded / socket | Size and type per customer drawing |
| Accessories | Manhole, vent, drain, level sensor mount | Optional as per order |
Why Choose Our FRP Neutralization Tank?
In the acid-alkali neutralization process, reliability and chemical compatibility are paramount. Our tanks are hand-laid using advanced filament winding or contact molding techniques, ensuring consistent wall thickness and resin-rich inner surfaces. The result is a vessel that delivers exceptional corrosion resistance over a service life of 15–25 years with minimal maintenance. For example, the vinylester resin inner layer provides excellent resistance to both oxidizing acids and caustic solutions, reducing the risk of leaks and contamination.
Furthermore, the lightweight nature of FRP (approximately 1/4 the weight of steel) significantly reduces structural support requirements and installation costs. Our tanks can be supplied with prefabricated mounting brackets and lifting lugs for easy on-site positioning. We also offer turnkey services including pipe connection, agitator integration, and insulation if required.
Each tank is tested for structural integrity and leak-tightness before delivery, with optional third-party inspection available. We follow international standards such as ASTM D3299, BS4994, and ASME RTP-1 (upon request) for design and fabrication, ensuring compliance with global industrial norms.
Trust Our Experience – Your Chemical Process Partner
With over 15 years of expertise in FRP composite manufacturing and an annual export value between US$1.5–2.5 million, Hengshui City Yike Composite Materials Co., Ltd. has built a solid reputation among clients in more than 10 international markets, including North America, Europe, Southeast Asia, and the Middle East. Our dedicated engineering team works closely with you to design the optimal neutralization tank for your specific chemical composition, temperature profile, and space constraints.
We have successfully supplied thousands of corrosion-resistant vessels for applications ranging from pH adjustment in municipal wastewater plants to high-purity neutralization in semiconductor manufacturing. Our factory, located in Hengshui, Hebei, China, is equipped with advanced molding and testing equipment, ensuring consistent quality and timely delivery. Shipments are coordinated from Tianjin and Shanghai ports to any global destination.
We invite you to contact our sales team for a personalized quotation. Include your desired capacity, chemical composition, working temperature, and any special requirements. We guarantee a responsive service and a durable product that will perform reliably for years to come.
Frequently Asked Questions (FAQ)
-
Q: What makes FRP a better choice than stainless steel for neutralization tanks?
A: FRP offers superior resistance to a wider range of chemicals, especially chlorides and strong acids, where stainless steel may suffer pitting or stress corrosion cracking. FRP is also lighter, easier to install, and typically more cost-effective for corrosive environments. -
Q: Can you manufacture tanks for continuous neutralization processes?
A: Yes, our tanks can be designed with multiple inlet/outlet nozzles, baffles, and overflow weirs to support continuous flow operation. We can also integrate level control and pH monitoring ports. -
Q: What is the typical lead time for a custom FRP tank?
A: Lead time depends on complexity and capacity. For standard designs, it ranges from 20 to 40 working days after confirmation of order. Large or highly custom vessels may require 45–60 days. -
Q: Do you provide installation and commissioning support?
A: We provide detailed installation drawings and can arrange for on-site supervision by our technical team (travel expenses apply). Remote support via video call is also available. -
Q: How do I choose the right resin for my acid-alkali mixture?
A: Our engineers will evaluate your chemical list and recommend the appropriate resin (vinylester, epoxy, or polyester). Please provide the chemical names, concentrations, and operating temperature for accurate selection. -
Q: What warranties do you offer?
A: We provide a standard 12-month warranty against manufacturing defects from the date of shipment, covering workmanship and material integrity. Extended warranty options are available upon request. -
Q: Can the tank be used for both acidic and alkaline phases in the same process?
A: Absolutely. FRP tanks with a suitable resin system (e.g., vinylester) can handle alternating acidic and alkaline conditions without degradation, making them ideal for batch neutralization processes. -
Q: Do you provide certification for international shipping?
A: Yes, we can issue material test reports, hydrostatic test certificates, and packing lists as required. Third-party inspection (e.g., SGS, BV) can be arranged at additional cost.
