Welcome to Hengshui City Yike Composite Materials Co., Ltd. Since 2009, we have been a reliable manufacturer specializing in FRP composite products. Our Anti-Corrosion Fiberglass FRP Waste Acid Storage Tank is engineered specifically for waste acid recycling treatment workshops, offering exceptional durability against harsh chemicals. With a strong export track record to over 15 countries and annual export value reaching US$2.5 million, we deliver tanks that meet the rigorous demands of industrial acid management. This tank ensures safe, long-term storage while minimizing maintenance costs.
Key Features & Technical Specifications
- Superior Corrosion Resistance: Made from high-quality fiberglass reinforced plastic (FRP) with a resin-rich inner layer, the tank withstands sulfuric acid, hydrochloric acid, nitric acid, and other aggressive chemicals commonly found in waste acid streams.
- Tailored Capacity & Dimensions: Available in capacities from 500 liters to over 100,000 liters, with customizable diameters and heights to fit any workshop layout. Our engineering team works closely with clients to optimize dimensions for space efficiency.
- Lightweight yet Strong: FRP is one-third the weight of steel but offers comparable strength, reducing foundation costs and simplifying installation. The tank can be placed on standard industrial floors without heavy reinforcement.
- UV & Weather Resistant: External gel coat provides protection against ultraviolet light and environmental exposure, making it suitable for both indoor and outdoor installations.
- Seamless Construction: Using advanced filament winding or hand lay-up techniques (based on size), the tank has no welded seams, eliminating weak points that can lead to leaks.
- Low Maintenance: The smooth inner surface prevents scale buildup and is easy to clean. No need for regular coating or lining repairs as required by metal tanks.
Technical Parameters (Typical Range)
| Parameter | Specification |
|---|---|
| Operating Temperature | -40°C to 120°C (depending on resin type) |
| Design Pressure | Atmospheric to 0.3 MPa (customizable for higher) |
| Wall Thickness | 4 mm – 20 mm (designed per load requirements) |
| Fittings & Accessories | Manholes, nozzles, level indicators, vents, and drain ports (customizable) |
| Lining Layer | Resin-rich veil (C-glass or surface mat) for enhanced corrosion barrier |
Benefits for Waste Acid Recycling Workshops
- Extended Service Life: FRP tanks can last 15–20 years or more under normal acid storage conditions, far exceeding carbon steel or stainless steel tanks in acidic environments.
- Cost-Effective Investment: Lower initial cost compared to exotic alloys, plus reduced maintenance expenses. Our tanks are often 30–40% cheaper than equivalent stainless steel tanks.
- Safe & Reliable: Non-conductive material eliminates galvanic corrosion. The tank is also non-sparking, making it safe for flammable acid vapors.
- Eco-Friendly: FRP is inert and can be recycled at the end of its life. No toxic coatings are required, supporting green manufacturing goals.
- Quick Installation: Due to lightweight, installation can be completed in 1–2 days for standard sizes, minimizing workshop downtime.
Our Commitment & Trustworthiness
Hengshui City Yike Composite Materials Co., Ltd. has been dedicated to FRP manufacturing for over a decade. With an annual export value of US$1.5 million – US$2.5 million, we serve clients across North America, South America, Europe, Asia, Africa, and Oceania. Our main ports of shipment are Tianjin, Shanghai, and other major Chinese ports. We have successfully delivered thousands of custom FRP tanks to workshops handling waste acid recycling, municipal wastewater, and chemical processing. Each tank undergoes rigorous quality checks including hydrostatic testing and holiday detection. We offer comprehensive after-sales support, including installation guidance and replacement parts. Choose Yike for a tank that performs reliably for years. Contact us today to discuss your specific waste acid storage needs.
Frequently Asked Questions (FAQ)
Q1: Can this tank store high-concentration sulfuric acid (98%)?
A: Yes, our FRP tanks can be designed with special resin systems (e.g., vinylester or epoxy) that are compatible with concentrated acids. Please provide the exact chemical composition and temperature parameters for a customized solution.
Q2: What is the typical lead time for a custom-sized tank?
A: For standard sizes (up to 10,000L), lead time is approximately 15–25 working days. Larger or highly customized tanks may require 30–45 working days.
Q3: Do you offer installation services or only supply the tank?
A: We primarily supply the tank with detailed installation drawings. For international clients, we can arrange on-site technical supervision upon request (additional charges apply).
Q4: How do I determine the required wall thickness for my application?
A: Our engineering team calculates wall thickness based on diameter, liquid pressure, specific gravity of acid, and operating temperature. We provide a free design proposal once you share the required parameters.
Q5: Is the tank UV-resistant for outdoor use?
A: Yes, we apply a UV-stable gel coat (typically ISO-NPG type) that protects the laminate from sunlight degradation. Outdoor tanks are also available with additional UV shielding options.
Q6: What accessories can be included with the tank?
A: We can add manholes (sizes 400–600mm), various inlet/outlet nozzles (flanged or threaded), level gauges (magnetic or ultrasonic), vents, and overflow ports. All accessories are made of FRP or compatible materials.
Q7: How long does the warranty last?
A: We offer a standard 12-month warranty against manufacturing defects. Extended warranties are negotiable for large projects.
Q8: Can you provide certificates of material compliance?
A: Yes, we can issue a material test report (MTR) for the FRP laminate and a hydrostatic test certificate upon request.
