Continuous Tunnel Type Industrial Microwave Oven for Wood Drying Heating Sterilization Equipment
Fast Drying • Uniform Heating • Continuous Automatic Production
✔ Tunnel Conveyor Design
✔ Energy Saving Technology
✔ PLC Intelligent Control
✔ Large Capacity Production
✔ 2450MHz / 915MHz Available
Microwave Machine in Wood Industry advantage:
1. Microwaves can dry wood rapidly, if 25-50L pine board microwave drying can be faster than normal drying 20-30 times, wood moisture from 30% low down to 12% only need 3-5 minutes
2. Uniform drying wood, non-deformation, non-cracking, both inside & outside of the wood treated by microwave heating is uniform, so heating quality is excellent,surface will not harden, but also can correct the bending too;
3. Microwave can kill inside insect eggs rapidly, prolong the wood shelf life.
4. High efficiency; the utilization rate of microwave as energy can reach over 75%, but the infrared & steam drying reduced more than 50%;
5. Easy to operate and save labor
Microwave can dry wood rapidly & evenly, no cracker, and also kill insect eggs inside of wood, so widely used in kinds of wood product heating, like wooden plywood, pure wood, chopsticks, and other wood products, etc.
Suitable for:
Wooden Boards
Bamboo Products
Furniture Materials
Wood Veneer
Timber Processing
Decorative Wood Panels
-
Our industrial microwave oven adopts advanced microwave penetration heating technology to rapidly dry wood materials from inside to outside.Compared with traditional hot air drying systems, microwave technology offers:
✔ Faster drying speed
✔ Uniform internal heating
✔ Lower energy consumption
✔ Continuous automatic production
✔ Better product qualityWidely used in wood processing factories and furniture industries.
Machine Advantages
✔ Fast Internal Heating
Microwave energy directly heats moisture inside wood materials for rapid drying efficiency.
✔ Uniform Drying Effect
Reduce cracking, deformation and uneven moisture problems.
✔ Continuous Production
Tunnel conveyor structure supports automatic industrial production.
✔ PLC Intelligent Control
Automatic adjustment of:
Microwave power
Conveyor speed
Temperature
Drying time
✔ Energy Saving Technology
Compared with traditional drying systems, energy consumption can be reduced significantly.
✔ Environment Friendly
No smoke, low noise and clean production process.
Technical Specifications:
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request
China Gspring Machine are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch microwave oven for lab use or for
small capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma industry etc. We have more than 10 years
experience on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam, Indonesia, Pakistan,Philippines, Brazil, Egypt,
Czech, Singapore, Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
We are the professional supplier for high quality industrial microwave oven if any questions about the machine, pls email:
