Factory Price Industrial Microwave Dryer Machine for Wood / Ceramics Multi Purpose Use
Product Introduction:
The Industrial Microwave Dryer Machine is a multi-purpose drying solution designed for efficient moisture removal in wood processing and ceramic manufacturing industries. Equipped with advanced microwave heating technology, the system provides rapid internal heating, continuous production capability, and lower operating costs compared with traditional drying methods.
This equipment supports customized production requirements and is suitable for industrial factories seeking stable output, reduced drying time, and improved product quality.
Key Features
1. Multi-Purpose Industrial Application
One system supports drying for wood products, ceramic materials, building materials, and various industrial products.
2. Fast Microwave Drying Technology
Microwave energy penetrates materials directly to accelerate moisture evaporation and shorten production cycles.
3. Continuous Production Operation
Automatic conveyor structure supports uninterrupted industrial manufacturing and higher output.
4. Energy Saving Performance
Improved thermal efficiency reduces energy consumption and lowers overall production costs.
5. Intelligent PLC Control System
Automatic adjustment of power, temperature, and conveyor speed ensures stable process control.
6. Uniform Moisture Removal
Achieves consistent drying quality while reducing deformation, cracking, and uneven heating.
7. Factory Direct Supply
Competitive pricing with customized solutions for industrial production requirements.
Application Scope
Suitable for:
Wood board drying
Decorative wood panel processing
Ceramic products drying
Ceramic green body moisture removal
Building materials industry
Composite board production
Industrial material dehydration
Working Principle:
Materials enter the microwave tunnel through a continuous conveyor system. Microwave energy acts directly on water molecules inside the product, generating heat internally and enabling rapid and uniform drying. This process improves efficiency and maintains stable product quality.Our industrial microwave oven
Why Choose Our Microwave Dryer?
✓ Factory direct competitive pricing
✓ Continuous large-capacity production
✓ Reduced drying time
✓ Uniform product quality
✓ Energy-saving operation
✓ Easy maintenance
✓ Customized engineering support
Factory price industrial microwave dryer machine for wood and ceramics with multi purpose design, continuous production, fast uniform drying,
PLC automatic control, energy saving operation, and customized industrial processing solutions.
Technical Specifications:
Machine Model |
GS-20HMV |
GS-40HMV |
GS-60HMV |
GS-100HMV |
GS-200HMV |
Work Frequency |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
2450±50MHZ |
Rated Apparent Power |
≤25KW |
≤50KW |
≤75KW |
≤120KW |
≤240KW |
Output Power |
≥20KW |
≥40KW |
≥60KW |
≥100KW |
≥200KW |
Dehydration Capacity |
16-20kg/hour |
30-40kg/hour |
48-60kg/hour |
80-100kg/hour |
160-200kg/hour |
Work Process Temperature |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
70-200℃ |
Cooling Type |
Water Cool/Air Cool |
Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool | Water Cool/Air Cool |
Work Time |
24h Continuously Work |
24h Continuously Work | 24h Continuously Work | 24h Continuously Work | 24h Continuously Work |
Operation |
PLC & Touch Screen |
PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen | PLC & Touch Screen |
Feeding Inlet Height |
40-100mm |
40-100mm | 40-100mm | 40-100mm | 40-100mm |
Belt Height |
60-1000mm |
60-1000mm | 60-1000mm | 60-1000mm | 60-1000mm |
Belt Running Speed |
0-4.5m/min or Customized |
0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized | 0-4.5m/min or Customized |
Belt Width |
500±100mm |
800±100mm |
800±100mm |
1000±100mm |
1200±100mm |
Belt Material |
Teflon Material or Customized |
Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized | Teflon Material or Customized |
Size |
8640×1220×2200mm |
10960×1500×2200mm |
13200×1500×2200mm |
15600×1700×2200mm |
22560×1900×2200mm |
Remark: Above parameter is for reference. All microwave dryer specific parameter need to be designed based on customer’s specific industrial request
Industrial Microwave Dryer Machine
Factory Price Microwave Dryer
Wood Microwave Dryer
Ceramic Microwave Drying Equipment
Multi Purpose Microwave Dryer
Continuous Microwave Drying Machine
Industrial Drying Equipment
Microwave Dryer for Wood Processing
Microwave Dryer for Ceramics
Industrial Microwave Heating System
China Gspring Machine are the manufactuer of Industrial Microwave Dryer, we can supply different kinds of microwave drying machine, like batch microwave oven for lab use or for
small capacity industrial use, industrial automatic tunnel mircrowave dryer, vaccum dryer specially for food & pharma industry etc. We have more than 10 years
experience on export, export to all over the world, like USA, Canada, Russia, India, Sri Lanka, Turkey, Vietnam, Indonesia, Pakistan,Philippines, Brazil, Egypt,
Czech, Singapore, Armenia, Iraq, Iran, Malaysia, Bangladesh, Mexico, Peru, Algeria, Poland, Thailand, Nepal, Azerbaijan etc.
We are the professional supplier for high quality industrial microwave oven if any questions about the machine, pls email:
