Introduction：
Cerium-doped gadolinium aluminum gallium garnet crystals, abbreviated as Ce:GAGG crystals, have
the chemical formula Ce:Gd₃Al₂Ga₃O₁₂.This crystal exhibits outstanding properties including high density, high
transmittance, large effective atomic number, high light yield, fast decay time, excellent energy resolution, stable
physical and chemical properties, absence of spontaneous radiation, non-hygroscopic nature, and favorable
processing characteristics. Consequently, it is regarded as one of the most superior crystals among numerous oxide scintillators.
Ce:GAGG crystals exhibit high optical output response at the 540nm wavelength band, enabling excellent
matching with silicon photodiodes. This crystal can be grown in large sizes with good machinability, supporting array products with up to 128 channels and minimum pixel sizes as small as 0.3mm.
The Ce:GAGG crystal's excellent scintillation properties and physicochemical characteristics enable its
widespread application in high-energy particle detection, nuclear physics, medical imaging, security screening, and
industrial detection. Its fast decay and low afterglow characteristics, in particular, make it exceptionally well-suited
for PET imaging systems and other imaging applications such as human body imaging, industrial inspection,
non-destructive testing, security screening, and X-CT.
