WOODWARD 9907-023 Electronic speed control
The Woodward 9907-023 is primarily used to control engine or turbine speeds and ensure even power distribution during parallel operation.
1. Core Control Functions
* **Speed Control:** Receives signals from a magnetoelectric speed sensor (MPU) and adjusts the actuator output to precisely stabilize the engine speed at a set value.
* **Load Sharing:** When multiple generators are operating in parallel, it communicates with each other via load sharing lines to ensure that each generator shares the load proportionally to its capacity.
* **Ramp Control:** Allows setting the acceleration time from idle to rated speed, reducing mechanical shock and black smoke during startup.
* **Start Fuel Limiting:** Prevents excessive fuel supply during startup, protecting the engine and optimizing emissions.
Email: xmxblynn@163.com
Phone: +86 18059884797
Operating Modes
Isochronous Mode: Maintains a constant frequency (speed) regardless of load changes.
Droop Mode: Speed decreases slightly with increasing load; commonly used in parallel with the power grid or in simple, non-automated parallel systems.
3. Technical Characteristics
Low Voltage Version: This model (9907-023) is typically a low-voltage input version (20–40 Vdc).
Interference Immunity: Possesses excellent immunity to electromagnetic interference (EMI) and radio frequency interference (RFI).
Multi-Sensor Support: Compatible with multiple speed ranges, switchable via internal DIP switches or potentiometers.
Application Areas
Due to its high reliability and adaptability to different prime movers, it is widely used in:
Diesel/Gasoline Generator Sets: Backup and main power systems in hospitals, data centers, and factories.
Marine Propulsion and Power Systems: Parallel operation and load distribution of marine main generator sets.
Steam/Gas Turbines: Speed control for industrial waste heat power generation or small turbines.
Pump Station Control: Large industrial water pump or oil pump drive units requiring precise speed regulation.
Email: xmxblynn@163.com
Phone: +86 18059884797
