WOODWARD XU1-E Protection relay
Core Functions Introduction
The primary function of the XU1-E is as a "sentinel" in industrial power systems. Its core monitoring capabilities include:
Dual Voltage Monitoring: Simultaneously provides overvoltage (U>) and undervoltage (U
Voltage Value Setting: Users can precisely set the voltage percentage threshold for triggering alarms or cutting off circuits based on the device's rated values.
Time Delay Protection: Supports adjustable time delays to prevent false triggering caused by instantaneous power grid fluctuations (surges or dips).
Multi-Phase Monitoring: Typically used to monitor three-phase AC systems, it can identify anomalies in single or multiple phases.
Self-Diagnostic Function: The device continuously performs internal self-checks and notifies the user via alarm contacts when a fault is detected.
Email: xmxblynn@163.com
Phone: +86 18059884797
Due to its high reliability and response accuracy, the XU1-E is widely used in the following fields:
Generator Protection:
Monitors generator output voltage. If the automatic voltage regulator (AVR) fails, causing excessively high or low voltage, the relay will immediately trip to prevent damage to downstream loads or generator windings.
Transformers and Substations:
Used in substations to monitor bus voltage and ensure power quality meets standards.
Motor Protection:
Prevents motors from starting under undervoltage conditions (which would cause a surge in current and severe overheating) or operating under overvoltage conditions (which would break down insulation).
Automatic Power Switching System (ATS):
As a logic element, it triggers a signal to switch to backup power or start the generator when the main power supply voltage is unstable.
Features and Specifications:
Installation: Standard DIN rail mounting or recessed mounting
Display: Typically includes LED indicators to show fault type (overvoltage/undervoltage)
Contact Outputs: Equipped with standard passive alarm contacts for connection to the circuit breaker trip coil
Measurement Frequency: Compatible with 50Hz or 60Hz systems
