A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump

A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump thumbnail-1
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump thumbnail-2
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump thumbnail-3
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump thumbnail-4
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump thumbnail-5
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump photo-1
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump photo-2
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump photo-3
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump photo-4
A+++ R290 8.6kw,9.5KW,12KW,15KW Monobloc Full DC Inverter Heat Pump photo-5
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Certification:
CE, ISO9001, CCC, ROHS, Other, TUV
Application:
Villa Family, Sauna and Swimming Pool, Hotels, Factory Hospital, Student Apartments, Beauty Salons, Other
Heat Source:
Air-source
Contact Supplier Request Quote Chat Now
Guangzhou Canova Heating & Refrigeration Equipment Co., Ltd
Verified Business License
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Certification CE, ISO9001, CCC, ROHS, Other, TUV
Application Villa Family, Sauna and Swimming Pool, Hotels, Factory Hospital, Student Apartments, Beauty Salons, Other
Heat Source Air-source
Energy Efficiency Grade One
Heat Temperature 50-70°C
Work Environment Low-temperature Heat Pump
Heating Type Multi-power Heat
Transport Package Plywood case
Specification 8.6KW
Trademark Canova
Origin Guangzhou, China

This series-Full Dc Inverter Heat Pump is splendid for domestic central heating and cooling with fan coil units,which its water pump built in.The water tank connection with this heat pump does not have copper coil heat exchanger inside,which saves the cost of water tank.

DC inverter heat pump can reduce more starting time than normal  heat pumps.It also can adjust the operating speed of the compressor and fan to extend the working life of the machine.

Model
KFV200-B/E KFV240-B/E KFV400-B/E KFV480-B/E
ErP Level(35ºC)
A+++ A+++ A+++ A+++
ErP Level(55ºC)
A++ A++ A++ A++
Heating (A7/W35) capacity range KW 3.7-8.6 4.2-10.3 5.1-12.2 5.6-15.6
input power range KW 0.75-2.06 0.87-2.52 1.05-2.93 1.15-2.76
Heating (A7/W45) capacity range KW 3.2-7.3 3.8-9.3 4.5-10.6 5.1-14.5
input power range KW 0.98-2.47 1.18-3.18 1.38-3.59 1.57-4.95
Cooling (A35/W7) capacity range KW 2.5-6.0 3.2-8.6 3.92-10.8 3.95-12.6
input power range KW 2.5-6.0 3.2-8.6 3.92-10.8 1.19-4.47
Power Supply
             220V~230V/1PH  220V~230V/1PH            380V~415V/3PH
Controller
                                          LCD Wire Controller
Compressor
DC Inverter Twin Roary
Condensor
Brazed Plate Heat Exchanger
Pipe connector
G1'' external thread
Air flow
 m3/h 2700 2900 4000 5000
Max outlet heating medium temperature ℃   25-70
Refrigarant
R290
Noise dB(A) ≤59 ≤64 ≤65 ≤67
Dimension mm 1060*420*1014 1060*420*1014 1060*420*1014 1060*420*1037
Weight kg 106 106 112 132


变频机1-2

变频机2

Features

  • Hybrid solar connection(optional)

  • Panasonic compressor with R290 refrigerant.

  • Heating + Cooling + Hot water

  • Anti-freezing work in -35 degrees low temperature.

  • Thermostatic heating element for evaporator and anti-frosting protection.

  • Energy-saving 80%.

  • Automatic defrosting function included (With reverse valve inside).

  • Water pump installed inside.

  • OEM/ODM service



未标题-2


Product Tags: Full DC Inverter heat pump , R290 heat pumps , Monobloc heat pump
