Home > Products > Other Brands > EATON XVS-440-10MPI-1-10 Touch Screen Controller

EATON XVS-440-10MPI-1-10 Touch Screen Controller

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Payment TermsT/T PayPal Western Union

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Material	Other, Global universal model	Condition	Other, Global universal model
Task	Other, Global universal model	Mathematical Model	Other, Global universal model
Signal	Other, Global universal model	Customized	Non-Customized
Structure	Other, Global universal model	Humidity	10–95% (non-condensing)
Weight	3.7 kg

Product Description

EATON XVS-440-10MPI-1-10

Overview

The EATON XVS-440-10MPI-1-10 provides users with an intuitive touch interface, enabling operation of control systems via the touchscreen and real-time acquisition of data and information. It meets various industrial application needs such as equipment control and parameter setting.

Functional Features

Convenient Operation: Equipped with an intuitive touch interface, supporting operations like equipment control, parameter setting, data input, and alarm handling.
Visual Display: Displays data in the form of graphics, charts, curves, etc., helping users intuitively understand the operating status and performance parameters of equipment or systems.
Strong Communication Capability: Features an Ethernet interface and supports communication protocols such as RS232 and Profibus/MPI, enabling data interaction with multiple devices.

Technical Parameters

Display Size: 10.4 inches.
Resolution: VGA (640×480 pixels).
Display Type: TFT color display.
Number of Colors: Adjustable to 65,536 colors or 256 colors.
Touch Technology: Infrared touch.
Interfaces: 1× Ethernet 100base-TX/10base-T interface, 1× RS232 interface, 1× PROFIBUS/MPI interface, 2× USB Host interfaces, 1× USB Device interface.
Protection Level: Front IP65, Back IP20.
Operating Temperature: 0–50°C.
Operating Humidity: 10–95% (non-condensing).
Weight: 3.7 kg.

Working PrincipleTouch Input Processing

The touchscreen adopts infrared touch technology. When the user touches the screen, the touch sensor detects the touch position and converts it into electrical signals. These signals are transmitted to the processor through the internal circuit of the controller, which parses the signals to identify user operation commands such as button clicks and swipes.

Data Processing and Logic Execution

The touchscreen integrates a microprocessor running an embedded operating system (e.g., Windows CE). The microprocessor logically processes touch commands according to preset application programs. For example, if the user clicks the "Start Equipment" button on the screen, the processor generates corresponding control signals as programmed.

Communication Interaction Mechanism

The touchscreen is equipped with an Ethernet interface and supports communication protocols such as RS232 and Profibus/MPI. Through these interfaces and protocols, it sends user commands to external devices (e.g., PLCs, frequency converters) and simultaneously receives real-time data from these devices (e.g., equipment operating status, parameter values), enabling bidirectional data transmission.

Display Driving and Interface Rendering

The touchscreen is equipped with a color TFT display. The display driver chip converts the image data processed by the processor into driving signals required by the LCD, achieving screen display by controlling the deflection of liquid crystal molecules in combination with the backlight module. With a resolution of 640×480 pixels and support for 65,536 or 256 colors, it displays data in the form of graphics, charts, curves, etc., helping users intuitively understand equipment status.

System Management and Storage

Based on the Windows CE operating system, the touchscreen manages hardware resources (including memory, communication ports, etc.). It supports using CompactFlash cards to store user programs, recipe data, alarm logs, etc., and has a power-off data retention function to ensure data is not lost during power outages.

Common Faults and Solutions

No Touch Response: May be caused by faulty infrared emitting/receiving tubes or foreign objects blocking infrared rays on the screen surface. Check and clean the screen surface; if ineffective, inspect the infrared touch components and replace damaged parts.
Abnormal Screen Display (e.g., black screen, screen flickering): May result from power failure, display driver circuit issues, or screen damage. First, check the 24V power input; then inspect the display driver circuit connections for looseness. Replace the driver circuit or screen if damaged.
Communication Failure: May be due to damaged communication cables, loose interfaces, or incorrect communication parameter settings. Check the integrity of communication cables and tighten interfaces; ensure communication parameters (e.g., baud rate, data bits, stop bits, parity) match those of the connected device.
System Freezing: May be caused by insufficient memory due to excessive running programs or program errors. Try restarting the touchscreen; if freezing occurs frequently, check running programs, optimize code, and close unnecessary background tasks.
