Help CenterLQ170E1LG21 SHARP 17.0 Inches
Related Products
Panel brand Sharp
Panel model LQ170E1LG21
Panel size 17.0 inches
Panel type a-Si TFT-LCD, LCD module
Resolution 1280(RGB)×1024, SXGA, 96PPI pixel layout RGB vertical stripes
The display area is 337.92 (w) × 270.336 (h) mm.
The external dimension is 358.5 (w) × 296.5 (h) × 13.4 (d) mm.
The visual size is 341.6 × 274.0 mm (H×V).
Surface treatment fog surface, Hard coating (3H)
Brightness (CD/M) 350 (typ.) Contrast ratio 1000: 1 (Typ.) [transmission]
Angle 6 o'clock optical mode TN, normally white display, transmissive
Viewing angle 80/80/80/70 (Typ.)(CR≥10)
Response speed 30 (Typ.)(Tr+Td) ms
Color quantity 16.2M, 100% sRGB backlight type WLED, 70K hours, including LED driver.
Screen weight of 1.20Kgs (Max.) is suitable for
Refresh frequency 60Hz Touch function no touch.
Signal system LVDS (2 ch, 8-bit), terminal, 30 pins
Supply voltage is 5.0V (Typ.).
Rated storage temperature:-30 ~ 70 C and working temperature:-20 ~ 70 C.
