Panel brand Sharp
Panel model LQ201U1LW11Z
Panel size 20.1 inches
Panel type a-Si TFT-LCD, LCD module
The resolution is 1600 (LCR) × 1200, and the pixel layout of UXGA and 99PPI is LCR vertical stripes.
Display area 408(W)×306(H) mm
The external dimension is 436 (w) × 335 (h) mm.
Visible area 413.2(W)×311.2(H) mm
Surface treatment of fog surface, Hard coating (2H)
Panel brightness 700 cd/m² (Typ.)
Contrast ratio 1000:1 (Typ.) (TM)
Viewing angle 85/85/85/85 (Typ.)(CR≥10)
Working mode ASV, normally black display, transmissive
Angle of view All-angle reaction time 5/20 (Typ.)(Tr/Td)
Display color gray scale
Type of light source: 6 pcs CCFL, 50K hours, excluding driving.
Touch screen with working frequency of 60Hz has no touch.
Panel weight 3.80Kgs (Max.) Panel application signal interface LVDS (2 ch, 8-bit), 40 pins, terminal.
Screen driving voltage is 12.0V (Typ.)
Working environment: 0 ~ 50 °C; Storage:-25 ~ 60 c
