Help CenterLQ190N1LX01 SHARP 19 Inches
Related Products
Panel brand Sharp
Panel model LQ190N1LX01
Panel size 19.0 inches
Panel type a-Si TFT-LCD, LCD module
The resolution is 1680 (RGB) × 1050, and the pixel layout of WSXGA+and 104 PPI is RGB vertical stripes.
Display area 409.5(W)×255.94(H) mm
The external dimension is 444 (w) × 283.3 (h) mm.
Opening area is 413.9 (horizontal) ×260.3 (vertical) mm.
Surface treatment fog surface (Haze 3%), Hard coating (3H)
Display brightness of 300 cdm² (Typ.) and contrast ratio of 9001 (Typ.) (transmission)
Recommended viewing angle-response time 35 (Typ.)(Tr+Td) ms
Viewing angle 85858585 (Typ.)(CR≥10)
Display mode TN, normally white display, transmissive
Support color 16.7M, 71% NTSC.
Type of light source WLED, 50K hours, including LED driver.
Weight 1.6Kgs (Typ.) Application product frame frequency 60Hz.
Touch technology touchless interface type 30 pins LVDS (2 ch, 8-bit), terminal
The voltage supply is 12.0V (Typ.) and the working temperature of the application environment is 0 ~ 50 °C; Storage temperature-20 ~ 60 c
