ZAY7040V Variable Speed Gear Driven Drilling Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
ZAY7045G Round Column Gear Driven Manual Drilling and Milling MachineNegotiableMOQ: 1 -
ZAY7020VL Vertical Mini Manual Drilling and Milling Machine With Longer WorktableNegotiableMOQ: 1
-
ZAY7025V Variable Speed Small Milling and Drilling Machine for Metal WorkingNegotiableMOQ: 1
-
ZX7550ZW Universal Milling Machine With CENegotiableMOQ: 1
-
ZX7550CW Universal Milling Machinery Cheap Milling Drilling Machine With CENegotiableMOQ: 1
Features:
Variable speed;
Milling,drilling,tapping,boring and reaming;
Head swivels +-45 degrees vertically;
Micro feed precision;
Adjustable gibs on table precision;
Strong rigidity,powerful cutting and precise positioning.
Specifications |
|||||
Model |
ZAY7032V |
ZAY7040V |
ZAY7045V |
||
Max drilling capacity |
32mm |
40mm |
45mm |
||
Max Face mill capacity |
Φ63mm |
Φ80mm |
Φ80mm |
||
Max End mill capacity |
Φ20mm |
Φ32mm |
Φ32mm |
||
Max distance from spindle nose to table |
400mm |
||||
Min distance from spindle axis to column |
260mm |
||||
Spindle travel |
130mm |
||||
Spindle taper |
MT3 , MT4 or R8 |
||||
Range of spindle speed |
100-530rpm 530-2600rpm |
||||
Swivel angle of headstock (perpendicular) |
±90° |
||||
Table size |
800×240mm |
||||
Forward and backward travel of table |
175mm |
||||
Left and right travel of table |
500mm |
||||
Motor Power |
1.1KW/1.1KW/1.5KW |
||||
Net/Gross weight |
300kgs/ 350kgs |
||||
Packing size |
770×880×1160mm |
||||
Loading amount/20" container |
36pcs |
||||
