Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE thumbnail-3

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE thumbnail-4

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE thumbnail-5

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE photo-1

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE photo-2

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE photo-3

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE photo-4

Parallel Lathe CK6432 Automatic CNC Lathe Machine With Good Price and CE photo-5

Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Business Type:

Manufacturer

Year Established:

2018

Factory Size:

Below 1,000 square meters

Contact Supplier Request Quote Chat Now

Jingjiang Fuji Technology Co., Ltd.

4Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Product Description

HOT SELL CNC LATHE MACHINE CK6432

Specification	CK6432×500/750mm
Max.swing over bed	Φ360 mm
Max.swing over carriage	Φ150 mm
Distance between centers	500/750mm
Spindle bore	60mm
Spindle nose	A2-6
Rail width	260mm
Taper of spindle bore	MT6
Chuck	8"
Range of speed (Variable)	150-2500 rpm
X axis travel	350mm
Z axis travel	500/750mm
X/Z rapid speed	4/7m/min
X/Z screw	2004/4006
Station of toolpost	4 or 6 or 8
Max. section of tool	20x20mm
Stroke of tailstock sleeve	100mm
Dia./hole of tailstock sleeve	50mm/MT4
Main motor power	3.7kw
Coolant pump power	120w
Overall dimenstion (LWH)	1740/2000x1210x1650mm
Packing size (LWH)	1960/2230x1410x1990mm
NW/GW	1275/1450kg;1450/1600kgs

Detailed Images

Company Profile

FAQ

Q1: How is the warranty?

A1: Warranty time is 13 months after BL date.

Q2:Can we visit your factory before order?

A2:Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.

Q3:Do you have a stock?

A3:Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.

Q4:What’s the MOQ?

A4:One set only.

Q5:How about your quality?

A5:We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.

Q6:Do you have professional engineers?

A6:Yes.we have professional engineers and designers. We can provide OEM services.

Q7:Can you provide customized machines?

A7:Yes, we can design and manufacture according to your specific requirements.
