CK6163 High Speed Cheap Cnc Lathe for Sale
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
360mm Spindle Bore Dia. QK1327 Pipe Threading MachineNegotiableMOQ: 1 -
LCK320 Cnc Lathe With High PrecisionNegotiableMOQ: 1
-
TCK46A Cnc Lathe Machine PriceNegotiableMOQ: 1
-
TCK6336L Slant Bed Cnc Lathe With High Precision From China FactoryNegotiableMOQ: 1
-
High Speed CK35G 350 mm Cnc Lathe Machine With Linear GuideNegotiableMOQ: 1
Features:
CK6163 CNC lathe is an economical and practical universal machine tool with stable mature product structure as well as stable quality and reliable performance. Widely used in automotive, petroleum, military and other industries. Shaft can be achieved both inside and outside surface of the disk and the like, cone ,arc, threading, boring, reaming process. The machine can be also processed to achieve a non-circular curve. Different control systems and accessories can be chosen according to the user’s needs.
MODEL |
CK6163/1500 |
|||||
Max.swing over bed |
630mm |
|||||
Max.swing over cross slide |
310mm |
|||||
Center distance |
1500mm |
|||||
Max machining length |
1200mm |
|||||
Spindle hole |
70mm |
|||||
Max.distance of moving tool-post |
||||||
Longitude |
1500mm |
|||||
Transverse |
350mm |
|||||
Spindle speeds(Number) |
14-750rpm(18steps) |
|||||
Main motor power |
11kw |
|||||
Speed of high-speed movement |
||||||
Longitude |
6m/min |
|||||
Transverse |
3m/min |
|||||
Feed resoving factor |
||||||
Longitude |
0.01mm |
|||||
Transverse |
0.005mm |
|||||
Toll numbers on tool-post |
4 |
|||||
Positioning accuracy |
||||||
Longitude |
0.03/500mm 0.05/2000mm |
|||||
Transverse |
0.02mm |
|||||
Repeatablity |
||||||
Longitude |
0.013/500mm 0.025/2000mm |
|||||
Transverse |
0.01mm |
|||||
Repeatablity accuracy of tool-post |
0.005mm |
|||||
NET.WEIGHT |
||||||
Center distance:1500mm |
3800kg |
|||||
FLOOR SPACE(LxWxH) |
||||||
Center distance:1500mm |
3452x1600x1950mm |
|||||
