Desktop Cnc Lathe CNC180 Benchtop Cnc Lathe Machine for Training and Hobby Use
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Manufacturer
Year Established:
2018
Factory Size:
Below 1,000 square meters
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
CK6163 High Speed Low Cost Cnc Lathe Machinery Price With Good QualityNegotiableMOQ: 1 -
CAK6161x1000 Lathe Machine From China Type Cnc Automatic LatheNegotiableMOQ: 1
-
CNC210 High Precision Mini Cnc Lathe for School TrainingNegotiableMOQ: 1
-
Desktop Cnc Lathe CAK6180x1000 Metal Cnc Machine for Making ScrewsNegotiableMOQ: 1
-
CK6136 X750 CNC Lathe Machine for Precision Threads Cutting for SaleNegotiableMOQ: 1
Product Description
Specification |
CNC180 |
CNC210 |
Max swing over bed |
180mm |
210mm |
Max.length of work pieces |
300/350mm |
400mm |
Spindle bore |
20mm |
26mm |
Spindle taper |
MT3 |
MT4 |
Spindle speed |
50-2250rpm |
100-3000rpm |
Metric thread cutting |
0.5-2.5mm |
0.25-4mm |
Inch thread cutting |
12-52TPI |
6-80TPI |
Electric toolpost |
4-position |
4-position |
X Travel |
60mm |
90mm |
Z travel |
250mm |
300mm |
X Moving speed |
800mm/min |
2000mm/min |
Z Moving speed |
1200mm/min |
2000mm/min |
Spindle motor power |
400w (optional:550w) |
1.2kw |
X Motor power |
1.5NM |
3NM |
Z Motor power |
2NM |
3NM |
Mini setting unit |
0.001mm |
0.001mm |
Tailstock diameter |
20mm |
22mm |
Tailstock Travel |
50mm |
50mm |
Tailstock taper |
MT2 |
MT2 |
Overall size |
900X400X1250mm |
1300*800*1500mm |
Net weight |
150kgs |
200kgs |
Detailed Images
Company Profile
Professional Service
FAQ
Q1: How is the warranty?
A1: Warranty time is 13 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure.All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: Sorry, most of our machines don’t have stock, we always produce according to order. However, if during fairs months, maybe have few samples back from fairs.
Q4: What’s the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 60 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes.we have professional engineers and designers. We can provide OEM services.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.
