Home > Products > HDMI CVBS Encoder > OTV-H48C HD SD H 264 Video Hardware 4 HDMI 8 CVBS AV to IP SRT RTMP Encoder for Live Streaming TV System
OTV-H48C HD SD H 264 Video Hardware 4 HDMI 8 CVBS AV to IP SRT RTMP Encoder for Live Streaming TV System
- 1000 Unit / Units per Month
- shanghai
- T/T L/C D/P D/A Credit Card PayPal Cash Escrow Other
- 1 days
- Dark Red Antique European antique desk lamp telephone for sale
- Antique European brown lamp telephone landline with home phones
- Antique European antique desk lamp home phones
- Antique gramophone gift music box player
- Classical turntable gramophone gift music box player
- Modern turntable gramophone gift music box player
Product Details
Brand Name: | DIBVIEWOLO | Place of Origin: | China | Model Number: | OTV-H48C |
Product Description
OTV-H48C IPTV Streaming Encoder accepts both 4*HDMI and 8*CVBS (A/V) input working at the same time. Meanwhile, it outputs 48 channels stream by TS over IP transmission in H.264 Compression(Video), AAC, MP3 Compression(audio) with different resolution and protocols for delivering services to multiple Internet connected devices at the same time, including smartphones, tablets, different size TVs and other mobile device. With powerful video pre-compression and efficient adaptive video compression algorithm, it is able to provide clear-delicate, high quality video even at lower bit rate within limited bandwidth.
OTV-H48C IPTV Streaming Encoder can be applied to education, health care, IPTV & OTT, conference, remote education, news interview, court, public security, banking, transportation and other industry applications.
Main Features:
Support4*HDMI+8*CVBSinput working at the same time.
Support up to 48 TS over IP stream out.
Support H.264 Main Profile/H.264 High Profile and MP3 & AAC audio compression
Bitrate mode: CBR/VBR
Capable of image parameter settings
Switchable of audio output mode: Left, right and Stereo
Configurable of Multi-rate, Multi-resolution, Multi-protocol
Providing RTSP/HTTP/UDP or RTMP protocol
Compatible with HDCP
Any terminal devices/decoders can have streams from IPTV Streaming Encoder directly by RTMP protocol with software players (such as VLC).
Support ONVIF Network Video Protocol
System supports WINDOWS XP/VISTA/SERVER2003/SERVER2008/WIN7 32 and WIN7 64, LINUX
Web-based management
Full-duplex mode 1000M
Key Specifications:
Video
Video compression: H.264/AVC High Profile Level 4.0
Video inputs:4*HDMI 1.3a version (support HDCP protocol) +8*CVBS(A/V)
Resolution:
HDMI main stream:
1920x1080,1680x1056,1280x720,1024x576,850x480,720x576,720x540,720x480,
720x404,704x576,640x480,640x360,auto
HDMI sub-stream:
1280x720,800X450,720x576,720x540,720x480,720x404,704x576,640x480,
640x300,352X288,320X240,320X180 auto
Bit-rate: 16kbps~12Mbps, CBR/VBR
Video pre-processing: Noise reduction, Sharpen, Filtering
Audio
Audio compression: AAC, MP3
Sampling rate: Adaptive, selectable of re-sample.
Sampling accuracy: 24-bit
Bit Rate: 48000,64000,96000,128000,160000,192000,256000
Re-sample:32000,44100
IP output
Transport protocol: TS over IP output, HLS, RTSP, HTTP, UDP and RTMP protocol
For each HDMI to IP output, supporting output 4 groups TS over IP streams (for each group the HTTP, RTSP, UDP and RTMP protocol all enabled). with 4 different resolutions (up to 1080p) and 4 different bitrates to meet different size screen and different bandwidth condition.
Connector: RJ45, 1000M
System
Configuration Interface: Web-based
Upgraded: via network
Connector: RJ45, 100M Ethernet interface.
Working Environment:
Voltage: 90-240V AC
Consumption: 15-20 W
Operating temperature: -10-70°C
Dimensions: 483mm(W)*240mm(D)*44.5mm(H)
Weight: 4Kg/pc
