Boron Nitride Powder Making Machine Fluidized Bed Opposed Jet Mill Microniser

 Boron Nitride Powder Making Machine Fluidized Bed Opposed Jet Mill Microniser

Air Jet Mill Microniser Features

1.Available particle size D50:1-25μm;

2.The jet mill is suitable for dry grinding of various materials with Moh’s hardness below 9, especially for the materials with high hardness, high purity and high added value;

3.The world’s leading high-precision classifier rotor with line speeds up to 80m/s, ensuring high precision for product requirements;

4.Grinding is in closed system, low dust and noise, clean and environmentally friendly production process;

5.Can be used in series with multi-stage classifiers to produce products with multiple sizes at one time.

Air Jet Mill Microniser Working Principle

Fluidized(Fluidised) bed opposed jet mill works with cyclone separator, dust collector and suction fan to form a complete grinding system.Compressed air flow after filtration and drying would go into milling chamber from nozzles, and meet in the center area, where material would be impacted and ground and sheared.

Milled powder would go up to the classifying chamber by the air flow from suction fan. The high-speed rotation of classifier wheel would create a strong centrifugal force to separate coarse powder and fine powder.Qualified fine powder would go through the wheel vane then into the cyclone separator or dust collector, while mixture of coarse powder and fine powder would fall down to the milling chamber to be milled again.

Applications of Boron Nitride Industrial Powders

Boron nitride is white (clean appearance), non-toxic and a non-conductor of electricity, and is an excellent substitute for other commonly used lubricants in metals processing such as graphite, molybdenum disulfide, and organic waxes and oils. In most cases, boron nitride substantially improves the efficiency of these applications.

The world’s leading high-precision classifier rotor with line speeds up to 80m/s, ensuring high precision for product requirements
