White Carbon Black Ultrafine Grinding High Purity Steam Air Jet Mill
Steam Jet Milling Features
Widely used in non-metallic minerals, chemical, industrial solid waste and other industries.
1.Available particle size D50:0.5-10μm;
2.Steam of working pressure 8-40 bar and temperature 230℃-360℃, both drying effect;
3.The grinding process is completed by the collision of the materials themselves., Fully self-grinding, So The device is durable and the purity of products is high;
4.The classifying wheel separates the material automatically with airflow, no coarse particles;
5.Grinding is in closed system, low dust and noise, clean and environmentally friendly production process;
6.Optional explosion-proof design, can also be upgraded to nitrogen circulation system to meet the ultra-fine grinding processing requirements of flammable and explosive oxide materials.
Steam Jet Milling Working Principle
Steam Jet Mill(Steam kinetic energy mill)
Upgraded by conventional jet mill, adopts unique high-temperature mechanical sealing technology, cooling technology, high-temperature steam as grinding kinetic energy medium, specially designed Laval nozzle drive high-speed collision and grinding of materials.
The grinded material enters the forced vortex classification, the qualified materials enter the heat preservation collection system, and the coarse materials fall into the grinding zone to continue the grinding, the whole process is completed under the dry process.
Application of White Carbon Black
Rubber products
White carbon black is used in colored rubber products to replace carbon black for reinforcement to meet the needs of white or translucent products. White carbon black also has super adhesion, tear resistance, heat resistance and aging resistance, so it can also replace part of carbon black in black rubber products to obtain high-quality rubber products.
Agricultural chemicals
In agricultural chemical products, such as pesticides, high-efficiency spraying fertilizers, etc., using white carbon black as a carrier or diluent, disintegrating agent, as a disintegrating agent in water dispersible granules wdg can increase the suspension rate, it is recommended to use the content of 10 %about. It can maintain long-lasting effectiveness because of its ultra-high surface area, high adsorption capacity, easy suspension, good affinity and chemical stability. Even under rain, washing and hot conditions, it can remain unchanged for a long time.
Daily chemical products
Transparent color and opaque toothpaste with white carbon black as filler and abrasive. This kind of toothpaste has good flexibility and dispersibility, the paste is smooth, soft, and abrasive, and does not abrade the toothpaste tube; it can keep the drug toothpaste Stable drug properties.
Cementing agent
Used in adhesives made of natural rubber or synthetic rubber, it provides thixotropy and reinforcement. At the same time, it can also improve adhesion due to its stretchability, which is high in quality and low in price.
Anti-caking agent
White carbon black can be used in some products to improve free flow, such as grass fertilizer, fungicide, grinding wheel abrasive, laundry bleach, phenolic injection molding urotropine, phenol and urea plastic products, manufacturing rubber sulfur and anti-caking Block mixture.
Papermaking filler
Using white carbon black as paper filler can improve the paper's resistance to ink penetration and mechanical strength, increase whiteness, and reduce unit weight. It can effectively reduce the weight of paper, reduce production costs, and improve paper performance.
In addition, it can also be used in many industries such as fire fighting agents, feed, cosmetics, matting agents, pigments, paints, etc.
(abbreviation: ALPA / Equity Code: 171033)
In the fields of ultrafine grinding and classification in the pharmaceutical, food, chemical, mineral, new materials, solid waste treatment and other industries, ALPA has mature and fully customized solutions and helps you design the ideal system to meet your needs.
Q: What service do you supply?
2). We supply sample processing tests in our test station where are equipped with our various machine products, to help clients compare performances of different types of machines or process.
3). We supply project engineering, automation engineering and civil engineering.
4). We send engineers to the clients’ project site and offer on-site technical instruction and supervision during the machine installation, commissioning and test run.
Q:How can I trust on your quality?
A: 1). All of the machine be tested successfully in Weifang workshop before shipment.
2). We supply one year warranty for all equipment and lifelong after-sales service.
3). We can test your material in our equipment before place the order, to ensure our equipment is suitable for your project.
4). Our engineers will go to your factory to install and debug the equipment, they will not be back until these equipment can produce qualified products.
Q:Does your company provide Engineers Abroad Service?
A: Sure, we provide it. And we can provide free training for on-site workers.
Q:How to train our staff about operation and maintenance?
A: We will provide detailed technical instructive pictures to teach them for the operation and maintenance. In addition, our engineers for guide assembly will teach your staff on site.
