Quality Guarantee Rebar Chamfering Machine Plant for Outside Angle Bevelling With Fast Speed
- Shanghai China
- T/T Credit Card
You May Like
-
MC-360Y Semi Automatic Hydraulic Different Angle Multi-blade Circular Saw Machine for Thick Wall Pipe Tube
-
MC-275B High Speed Pneumatic Circular Sawing Tube Cutter Mechanical Pipe Cutter Machine
-
High Speed Chamfer Rod Machine Bar Chamfering Tool for Solid Rod Deburring
-
New Design Low Noise Conical Tube End Forming Machine Pipe Taper Molding Machine for Steel Furniture
-
ZSG-60 Steel Pipe End Shrinking Machine Pipe Taper Reducing Machine With Low Noise for Conical Shape
-
MC-350CNC-S High Precision Fully Auto ss Pipe Cutting Machine for Steel Tube Sawing
Product Details
| Brand Name | CARE | Model Number | EF-AC/80 rebar chamfering machine plant |
Product Description
Quality guarantee rebar chamfering machine plant for outside angle bevelling with fast speed
Application:
This machine is controlled by pneumatic. Feeding / retracting and clamping by pneumatic, loading by hand. It has 2-step feed speed. The first step feed is high speed, then the second step feed speed is adjustable to produce clean and smooth cutting results. Changing sizes of cut are conveniently made by simply adjusting and changing cutter head and clamp.
Main characteristics:
1. Hand feeding, automatic blade driving and retracting, high speed, doubles the production capacity.
2. Fits for endface interior and external angles of pipes and bars, can finish the riveting and coping in a single time with quickness and good accuracy.
3. To ensure the stability of the centerline between the processing piece and saw plate, the clamping die and saw plate are precisely designed and can finish the processing evenly at a single time.
4. The saw plate is specially designed, saw blade standardized, the adjustment of blade is easy and quick.
Main parameter:
| Specification/Model | EF-PV/52 | EF-AC/80 |
| Main motor power | 1.5KW | 2.2kw |
| Main axis speed | According to the pipe material | |
| Processing diameter | 9-52mm | 30-82mm |
| Processing external angle | 9-25mm | 20-50mm |
| compressed air | 6-8GS/cm2 | 6-8GS/cm2 |
| Size | 450mmx 400mm x 800mm | 500mmx 400mm x 850mm |
| Weight | 300kg | 400kg |
Machine photo
Customize on demand
Chamfer outside angle
Chamfering inside angle
Chamfer facing angle
Pipe/rod sample
