Stainless steel pipe cutting machine Features:
Main Function:
- This machine adopts microcomputer
- It feeds, clamps and cuts material repeatedly according to preset program by matching with automatic pneumatic components.
- If combining with actual workpiece, particular clamp can be designed to cut several pipes at the same time, so the output is improved doubly.
- Counter is equipped on the machine to calculate cutting output.
- Automatic coolant pump,It keeps the the saw blade sharp and durable.Also the surface of pipe is clean and smooth.
Technical parameters:
| Model | JC-325-3A | |
| Head rotating angle | 90° | |
| Cutting capacity area | Solid bar | 55mm |
| Round tube | 110mm | |
| Angle steel | 100mm×100mm | |
| Square tube | 95mm×95mm | |
| Through-shaped steel | 100mm×100mm | |
| Retangular steel | 90mm×110mm | |
| Host motor | 2.4KW/2.0KW-2/4P | |
| Spindle speed | RPM 100/50 | |
| Cooling pump | 1/8HP | |
| Compressed air pressure | 4-6kgs/cm2 | |
| Circular saw blade(Diameter) | 250mm-350mm | |
| Feeding length | 3mm-650mm(Standard),can feed three times,total 1950mm | |
| Machine weight | 700kg | |
| Machine dimension(L×W×H) | 1000×1650×1700 | |
| Standard fittings | HSS Saw blade 275mm | |
| HSS Saw blade,one scale,one tool box,one set of clamping module | ||
Stainless Steel Tube:
Dies:
Structures :
Machine Picture :
Package :
Certificate :
Company Profiles :
with decades hard work and accumulated experiences, We have acquired fourty invention
patent,Utility model and appearance patent.Meanwhile, We have passed ISO9001:2008 quality system certificate, Government-issued Guangdong Province private technology enterprises, high-
tech enterprises, private enterprises and other honors.
The products include Super hard metal bar cold saw machine series, Chipless metal pipes circular saw machine series,Copper aluminum non-ferrous high-speed precision circular saw machine series,Metal pipe/bar end chamfer machine series,Circular saw blade sharpening machine series,Automatic pipe bending and forming Machine series , Six categories eighty models , Also provide customized complex process
Machine , all kinds of circular saw blade . Wide Application range contains Nautical
aviation and aerospace industry, military industry, high-speed rail and rail transportation
industry, auto industry, precision parts, medical and fitness equipment industry, mechanical and electrical and electronic industry, lighting and furniture decoration forty industries .
