MSG-450 High Speed Steel Circular Metal Disc Sharpener Machine
- T/T Credit Card
You May Like
Product Details
| Brand Name | CARE | Place of Origin | Jiangsu, China | |
| Type | Surface Grinding Machine | Certification | CE Certification | |
| After-sales Service Provided | Engineers available to service machinery overseas | Weight | 130kg | |
| Dimension(L*W*H) | 800mm x 800mm x 1410mm | Voltage | 380V | |
| Condition | New | Power(W) | 1.25kw | |
| CNC or Not | Normal | Max. Grinding Length | 8mm | |
| Max. Grinding Diameter | 50-450mm |
Product Description
MSG-450 High speed steel circular metal disc sharpener machine
Product Description
This machine is easy to operate, the cutting angle, tooth shape and tooth depth on the saw are easy to adjust, with a high precision, sharp and durable.
2. Quick adjustments can be made according to the various thicknesses of the coping saw bits.
3. The head section can be adjusted or swinged upward or forward willingly, coping and beveling can be made without exchanging the abrasive disk.
Technical parameter
Specification/Model | MSG-450 |
Diameter of saw blade | Φ50mm-Φ450mm |
Max distance of the tooth | 25mm |
Max depth of the tooth | 8mm |
Degree | -35 |
Feeding speed | 45-180 teeth/minute |
Max thickness of the blade | 8mm |
Diameter of the grinding wheel | Φ75mm-Φ150mm |
Speed of the grinding wheel | 4200RPM(60HZ) |
Driving motor | 1/2HP |
Grinding motor | 3/4HP |
Size | 800mm x 800mm x 1410mm |
Weight | 130kg |
Machine photo
More sets in STOCK
